BMPRO CONNECT+ - Diagnostics

DIAGNOSTICS
The Diagnostics screen displays any detected faults in the system, and allows
you to force reset the Node.
To clear circuit faults, remove the suspected short and toggle the suspected
output to clear the fault indicator.
A red fault indicator will appear if a fault is detected on the lights, tank
heaters, water heaters. water pumps, electric heaters, gas heaters or load
shedding.
An orange fault indicator will appear on the gas water heater button if a fault is
detected on the gas water heater output.
WARNING
Motor outputs do not indicate a warning if the wires are shorted.
