GPS INDICATION
Satellite reception, by the navigation system, is indicated in the upper right corner of the
display screen. The number of satellite signals being received by the system is indicated
by small white dots in the display that surround the picture of the globe. In addition, the
GPS logo is displayed at the bottom of the graphic.
The number of dots indicate the number of satellite signals that the navigation computer is
receiving.
If only the globe graphic is displayed, without the dots or logo, the vehicle is in a poor
reception area or the signals are being blocked by some obstruction. The dead reckoning
function of the compass and wheel sensors provide adequate navigation in this situation.
If the dots and logo fail to display in a known good reception area, than a fault is indicated
and troubleshooting should be carried out according to the fault symptom GPS Problems.
33
On-Board Monitor and Navigation Systems
