The following components are located on the rear parcel shelf under the trim
panel.
MAGNETIC FIELD SENSOR
The magnetic field sensor is a
small micro processor. It is used
while the navigation system is
operating to determine the
vehicles direction of travel.
GLOBAL POSITIONING
RECEIVER ANTENNA
The antenna picks up the signals
from the satellites and transmits
them to the GPS module.
Carry over components that are part of the On-Board Monitor / Navigation system
include:
Instrument Cluster Control Module (IKE) for On Board Computer calculations
Multi-Function Steering Wheel (MFL) for radio and telephone control functions.
Telephone handset for operation of the phone.
ASC control module for the two front wheel speed sensor inputs.
6
On-Board Monitor and Navigation Systems
