On-Board Monitor and Navigation Systems
GPS Antenna
The GPS antenna is directly connected to the navigation computer via a coaxial cable.
Locations of the antenna in the vehicles are as follows:
Display Units
Based on the particular model, the factory installed Mk-3 system is displayed using a color
board monitor or on a smaller monochromatic screen (MIR).
AM FM
MODE
TONE
SEL
MENU
12
34 56
AUDIO
NAVIGATION
TELEFON
A-TEMP
11.13.2000 Thursday 10:17
INFO
1
4
25
36
FM AM
MODE
MENU
TONE SELECT
MENU
On-board computer
DSP
Code
Set
GPS-Navigation
Monitor off
Emergency
Aux. Ventilation
DOLBY B-C NR
12
BMW
34
MODE
56
TONE SELECT
FM AM
PTY RDS
MENU
MONITOR
09/08/00 Friday 7:05 PM
MENU
On-board computer
Telephone
onitor Off
GPS-Navigation
Set M
Emergency
E52 MIR (Multi Information Radio)
E46/E53 Color Board Monitor
E38/E39 Wide Screen Color Board Monitor
(phased in for E53 1/01, E46 9/01)
E38: Under the rear parcel shelf.
E39 sedan: Under the rear parcel shelf.
E39 Sport Wagon: Behind the dashboard on the left side.
E46 sedan/coupe: Under the rear parcel shelf.
E46 Sport Wagon: Above the rear glass under the spoiler.
E46 Convertible: Behind the instrument cluster.
E52: Left front corner behind the dashboard.
E53: Above the rear glass under the spoiler.
