Specifications
Specifications
Line Level Inputs
Sensitivity (for 0.5 V output): 125 mV
Sensitivity-Phono: 1.6 mV
Frequency response:
20 Hz-20 kHz +/- 0.5dB
Signal to Noise (relative to 2V out): 88dB
Distortion (THD): < 0.03%
Separation (at 1 kHz): 70 dB
Tone Control:
Bass: +/- 10 dB (at 100 Hz)
Treble: +/- 10 dB (at 10 kHz)
Dolby Digital and DTS modes
Frequency Response:
Left and Right (Large): 20 Hz-20 kHz
Left and Right (small): 80 Hz-20 kHz
Center and Surrounds: 80 Hz-20 kHz
Subwoofer: 20-80 Hz
(The Sub plays the bass from the other
channels using Bass Management)
Signal to Noise (relative to 2V out): 88dB
Distortion (THD): < 0.03%
Delay adjustment in Dolby Digital:
Center: 0-5 mS in 1 mS steps
Surrounds: 0-15 mS in 1 mS steps
Delay adjustment in Dolby Pro Logic:
Surrounds: 15-30 mS in 5 mS steps
Video Section
Video inputs/outputs: 1Vp-p / 75 ohms
Component Bandwidth: 30 MHz, -1.5 dB
Composite Bandwidth: 6 MHz, -2 dB
S-video Bandwidth: 18 MHz, -1.5 dB
FM Tuner Section
FM range: 87.5-108 MHz, 0.1 MHz steps
Usable sensitivity (Mono):
1.6uV (75 ohms)
15.2 dBf (75kHz DEV, 30dB)
50dB quieting sensitivity (Stereo):
31.6uV (75 ohms)
41.2 dBf
Audio output frequency range:
30 Hz to 15 kHz, +.5dB, -3dB
AM Tuner Section
AM frequency range: 530-1700 kHz in
10kHz steps
Usable sensitivity (30% mod.,S/N 20 dB):
16uV / (600 uV/m)
Signal to noise (30% mod., 1mV input):
48 dB
Video Function Relay
12V Trigger out: 50mA maximum
Relay contact rating: 24 VDC 2A maximum
Power Requirements
120 VAC 50-60 Hz: 40 W
Dimensions
19” wide x 6.5” high x 15.5” deep
Net Weight
43 pounds
© 2001 Sunfire Corporation.
All rights reserved. Sunfire Corporation
reserves the right to improve its products at
any time. Therefore, specifications are subject
to change without notice.
Manual part number : 913-005-00 Rev B
