Step 5 Repeat to secure the Extension Torsion Arm (EQX2)
to the Torsion Plate using two M4 x 16 Machine
Screws each.
Step 6 Carefully turn the Assembly over and align the slots
in the Torsion Plate with the tabs on the Torsion
Arms.
