12.0 Spare Parts List
* Customer dependent and not shown in photos
Item #
Part Number
Description
1
422590-C
Stepper Motor with 20 teeth press fit pulley
2
P50-1017
Drive Belt, 98T (for 200dpi)
2*
P50-1003
Drive Belt, 102T (for 300dpi)
3
(1)
423760-L4B-1-200-u
Platen for 200 dpi UPG paper guide complete (.624 shoulder)
3
(1)
423760-L4B-1-300-u
Platen for 300 dpi UPG paper guide complete (.624 shoulder)
3
(1)
423760-L4B-200-
UADJ2
Platen for 200 dpi UPG ADJ2 paper guide complete (.624 shoulder)
3
(1)
423760-L4B-300-
UADJ2
Platen for 100 dpi UPG ADJ2 paper guide complete (.624 shoulder)
3
(1)
423760-L3B-1-200-p
Platen (UPG-R paper path) complete for 200dpi for plastic print cage only
3
(1)
423760-L3B-1-300-p
Platen (UPG-R paper path) complete for 300dpi for plastic print cage only
4
424008-U
Cutter Assembly (BC5) all model Lemurs with UPG paper guide
(Don’t include metal side plates) JST connector optos
5
AC161A5
LCD Display
6
423793
Energy Star Decal
7
423625
Rubber Feet (all printers except Lemur-K)
8
423192
Ground Strap
9
423496-ONEL4
Head Mounting Plate, plastic print cage ONLY (200L4 & 300L4 print heads only)
9A
423496-ONE
Head Mounting Plate, plastic print cage ONLY (200C3 print head only)
10
423236P
Take Out Head Cam Lock
11
423950-RET
Bushing, Platen retainer clip for UPG platen
12
SQ OPTO-L-U
SQ Load Opto, printers with UPG paper path
13
424060
Cable, Thermal Head (for 200L4 print head only)
13A
424059
Cable, Thermal Head (for 300L4 print head only)
13B
424010
Cable, Thermal Head (for 200C3 print head only)
14
(2)
200L4
Print Head (200dpi ADJ4 & RADJ4) 2L on s/n tag
14A
(2)
300L4
Print Head (300dpi ADJ4, RADJ4, AJDW, ADJ2, RADJW) 3L on s/n tag
14B
(2)
200C3
Print Head for 2C printers only
15
SQ OPTO-U
Opto Detector Assembly (opto) UPG paper path printers
16
423938-JST-BJ
DC Harness, cutter for JST sensor connectors for logic board w/ JDC JST connector
17
FGLBR46-E
Main Logic Board (Ethernet option) software ID of BR##
17*
FGLBR46
Main Logic Board (Standard) software ID of BR##
17*
FGLBR46-2C
Main Logic Board (PRINTER W/ 2C PRINT HEAD ONLY) software ID of BR##
17*
FGLBR46-E-2C
Main Logic Board – Ethernet (LEMUR-R OR PRINTER W/ 2C P.H.) software ID of BR##
17*
FGLBR46-BT
Main Logic Board – (Bluetooth/Wi-Fi option) software ID of BR##
17*
FGLBR46-E-BT
Main Logic Board – (Ethernet & BT/Wi-Fi option) software ID of BR##
17*
FGLBR46-RFID
Main Logic board – (RFID option) software ID of BR##
17*
FGLBR46-RFID-E
Main Logic board – (RFID option & Ethernet) software ID of BR##
17*
FGLBR46-E-600
Main Logic Board – Ethernet (600dpi print head) software ID of BR##
18
423952-B-20PT
Cabinet, Lemur-S
19
424009-L
Power Supply 24VDC (65W)
20
420880-CB-EXT
Printer Mounting Plate (including 65W power supply)
21
420880-EXT
Cabinet, Lemur
22
423480C
Upper Exit Deflector ONLY BC5 horizontal & vertical printer
23
422718WV
Anti-Static Brush (only) for both horizontal and vertical printers
24
423480C-C
Upper Exit Deflector BC5 horizontal (complete w/ static brush)
25
423829-1
Mylar only, (BC5) vertical lemur
26
423480C-VL
Upper Exit Deflector BC5 vertical (complete w/ brush & Mylar)
27
423485-VL
Lower Exit Deflector (vertical mount Lemur & Lemur-R)
28
424102LP-C
Rail UPG, left side complete (std opto)
29
424102RP-C
Rail UPG, right side complete (std opto)
30
424102LP-TOP-C
Rail UPG, left side complete (top opto)
31
424102RP-TOP-C
Rail UPG, right side complete (top opto)
32
423825-4x6
Hopper, (4” x 6”) Plastic
33
420881-EXT
Cover, Lemur
34
423952-C-2A
Board Cover
35
423952-C-20PT
Cover, Lemur-S
*
423824BF-3
Driver Pulley, 30T (for 300dpi) press fit (for distributors only)
*
423824BF-2
Driver Pulley, 20T (for 200dpi) press fit (for distributors only)
*
423824BF-1
Driver Pulley, 20T press fit Stepper motor (for distributors only)
*
P19-1000
Cable, AC cord 110VAC (US)
*
423855
Cable, AC cord 220VAC (European)
*
423856
Cable, AC cord 220VAC (UK)
*
423963
Cable, AC cord 220VAC (Australia)
*
423765
Cable External, serial DB9 TO RJ12
*
423846
Cable External, USB
*
423923
Fill-in plate, Display (for plastic electronics box)
*
421421Z-P
Top Plate, vertical Lemur (8.70” x 9.64”) Plastic cabinet Lemur
*
421421Z-PNC
Top Plate, vertical Lemur (13.00” x 9.48”) Plastic cabinet Lemur
*
421421Z-P-PA
Top Plate, vertical Lemur (10.25” x 10.25”) Plastic cabinet Lemur
