Layout and Function 3.2 Layout of the Control Unit
Page 10 BOGE base control for scroll compressors
3.2 Layout of the Control Unit
The control unit of the base control is structured as follows:
Fig. 3.1: base control – Control Unit
Both display and control elements can be found on the control unit.
Display Elements:
– LCD display (1)
– Indicator lamp – Fault (2)
– Indicator lamp – Ready (3)
Control Elements:
– Info key (4)
– Enter key (5)
– On key (6)
– Off key (7)
The individual elements and their functions are explained in more detail below.
(4)
(5)
(3)
(1)
(2)
(6)
(7)
