FIRE AND ALARM CONSOLE
14
If after delay elapsing entrance zone has been retaining in alarm, that is was not armed or
disarmed, the console generates “INTRUSION ALARM” message. Relay controlling programs
operate ‘INTRUSION ALARM’ and ‘ENTRY ALARM’ states by different ways (see Table 7).
For example, ‘SIREN’ programmed output is not turned on in ‘ENTRY ALARM’ partition state
with ‘Alarm output’ having being opened. Entrance zones assigned with the help of the console
effect only console controlled output operating algorithm and does not effect on outputs
controlled by intrusion and fire alarm panelss.
1.3 Delivery set
1.3.1 List of delivery set components of the console “S20000M” is shown in table 8.
Table 8 Delivery set of console ‘S2000M’
Name Quantity Note
Check and control fire-alarm ‘S2000M’ console
1
Check and control fire-alarm ‘S2000M’ console.
Maintenance guide.
1
Screw with 1-3х20.016
3
Dowel 8х35
3
Printer cable 1 Supplied for additional price
Personal computer communication cable 1 Supplied for additional price
1.4 Description the product and capabilities
1.4.1 Console has the plastic case. The printed-circuit board is mounted inside the case.
Wires are to be screwed connected to the terminal board. There is the LCD display at the top of
case. Under indicator from the right the LED indicators ‘READY’, ‘ALARM’, ‘FIRE’,
‘TROUBLE’ and ‘FAULT’ are located. Indicator ‘READY’ has green lighting with the others
ones have red lighting. Below indicators there is a keyboard with 20 keys. Keyboard has
supplied with the cover for dust and casual pressure protection. The layout, overall and mounting
dimensions are presented in appendix A.
