Console finished password enter if number typed symbols equal to value of the parameter.
Parameter ‘CODE LENGTH’ can be in range from 1 to 8 symbols (see item 2.2.4.4).
Identity code is input from the computer keypad or ‘S2000-K’, ‘S2000-KS’,
‘S2000-4’,‘S2000-2’,‘Signal-20P SMD’, or‘S2000-KDL’ devices, provided that they are polled by
means of program ‘pprog.exe’. Reading identifiers from the polled device is faster and more
useful then manual input. Device must be polled by program ‘pprog.exe’ to input identificator
code. If device is not polled, search this device on the tab ‘Devices’ in window ‘Search’. To set
code on tab ‘Password’ press button ‘Read code’ and touch Touch Memory key (Proximity-card)
to the reader. Key (card) code should be read and showed in ‘Code’ field. ‘S2000-KS’ or
‘S2000-K’ keyboard PIN-code should consisit from 4 digits. Such password can be programmed
without ‘pprog.exe’, from console ‘S2000M’. Password programming is described in the item
2.2.4.5.
To set device partition control privilegies select ‘Controlling abilities’ tab of ‘
pprog.exe’
program and drag reguired partition from ‘Partition’ window to the corresponding device in the
‘Controlling abilities’ window. In such a way each device is to be assigned with the list of
partitions available for controlling.
Note that TM or Proximity authority level should have controlling privilegies only for
single partition.
2.1.7.4 Setting control by system relay outputs
Console allows organizing up to 255 system outputs (‘open collector’ or relay) which
controlled according to the given algorithm on the basis of the partition states. Because ‘S2000’
console control by system outputs let call such control external (to differ from internal control
when receive-check device control by their outputs itself). To customize outputs it is necessary
select physical relays (device address and relay number in device), which will be used for system
control. Determine partitions that controlled by relay’s state (connect relay and partition).
Determine relay state dependence from state of connected partitions (select control program).
These settings are run by program ‘
pprog.exe’ when console configured. Control program
number is selected according Table 7. If output belongs to device, that support extended output
control (for example, S2000-SP1 version 1.20 or S2000-KPB), switching timeout can be set. For
outputs with time restricted program time control should be set. Control time and switching
delay are given in the range from 0 to 8191,875 seconds with interval 1/8 seconds. If control
time equal to 8191,875 seconds, then output will be switching on without time limitation. Setting
these parameters run by program ‘
pprog.exe’ when console configured. If device do not support
extended relay control, then their outputs will be switched without delay, and switching time will
be equal to the value of configuration parameter ‘Control time’ this relay. ‘Control time’
parameter is set with the help of the console or program ‘
uprog.exe’. Also, for relay outputs of
‘S2000-SP1’ it is necessarily to set value of ‘Control program of initial state’ parameter. This
parameter output state after switching on power of the device. It should be 0 (‘off’) or 1 (‘on’)
depending on console output program. If output control by programs, operated on switching on
(for example, programs ‘On’, ‘On for a time ‘, ‘Siren’, ‘ASPT’), ‘Control program of initial
state’ parameter value have to be 0 (‘off’). Output ‘S2000-4’, ‘Signal-20P’ and ‘Signal-20’ series
02 device initial state determined by parameter ‘Control program’. If output initial state has to be
‘off’, parameter ‘Control program’ has to have value 1, if ‘on’ - value 2. Parameters value
‘Control program of initial state’ and ‘Control program’ can be programmed in device both with
the help of console and with the help of program ‘
uprog.exe’.
