S2000M MAINTENANCE GUIDE
57
Appendix B Zone status list
Zone statuses are listed in priority decreasing order. If different zones of one partition
have various statuses, the resulting status of the partition will be defined by the zone status of the
highest priority. For example, if the zone statuses are "Zone armed", "Disarmed", "Loop short
circuit" and "Fire prealarm", then the resulting partition status is "Fire prealarm".
State Description Displayed
"EXTINGUISHING"
Fire extinguishing is in process (the launching pulse
was given out and outflow of fire extinguishing
agent has been detected)
EXTINGUISH
"EMERGENCY
LAUNCHING"
The launching pulse was not given out but outflow
of fire extinguishing agent has been detected
EMERG LNCH
"LAUNCHING"
The pulse for fire extinguishing equipment
launching was given out
LAUNCHING
"LAUNCH FAULT"
The fire extinguishing equipment was not
successfully launched (the launching pulse was
given out but outflow of fire extinguishing agent
has not been detected)
LNCH FAULT
"LAUNCHING
DELAY"
The condition for launching of fire extinguishing
equipment has met and launching delay is being
counted
LNCH DELAY
"LAUNCH
BLOCKED"
The launching of fire extinguishing equipment was
blocked up (e.g., due to the door opening to the
protected area)
LNCH BLOCK
"LAUNCH
CANCEL"
The launching of fire extinguishing equipment was
canceled (e.g., due to the command "Cancel
extinguish" given from console or to the pressing
"RESET" key of "S2000-ASPT")
LNCH CANCL
"FIRE ALARM"
Two threshold detectors in an alarm loop have been
activated, or fire delay has elapsed, or “Fire”
threshold of quantity measured by addressable
analogue zone (temperature or smoke) has exceeded
FIRE ALARM
"FIRE PREALARM"
There is probability of fire.
Threshold detectors in an alarm loop have been
activated, or alarm acknowledgment from a smoke
threshold detector, or "Prealarm" threshold of
quantity measured by addressable analogue zone
(temperature or smoke) has exceeded
F PREALARM
"SILENT ALARM",
or "ATTACK"
Silent zone alarm (usually controls alarm keys)
SLNT ALARM
"INTRUSION
ALARM"
Intrusion zone alarm (alarm loop has been broken
or alarm addressable detector has been activated)
ALARM
