Type password.
Select ‘DISARM’ menu item by ‘
4’, ‘3’ and ‘ENT’ keys, or
press hot key ‘2’.
Select ‘DISARM GROUP’ menu item by ‘
4’, ‘3’ and ‘ENT’
keys, or press hot key ‘2’.
Enter device number (valid value from 1 to 127), or select valid
address value by ‘
4‘, ‘3‘ keys and press ‘ENT’.
Common disarming
Type password.
Select ‘DISARM’ menu item by ‘
4’, ‘3’ and ‘ENT’ keys, or
press hot key ‘2’.
Select ‘DISARM ALL’ menu item by by ‘
4’, ‘3’ and ‘ENT’
keys, or press hot key ‘3’.
Enter device number (valid value from 1 to 127), or select valid
address value by ‘
4‘, ‘3‘ keys and press ‘ENT’.
2.2.3.2 Device alarm reseting
At this command device with given address transmits alarm turned on external device
outputs in initial state and arms alarm loop that in alarm or fire state.
Type password.
Select ‘ALARM RESET’ menu item by by ‘
4’, ‘3’ and ‘ENT’
keys, or press hot key ‘3’.
Enter device number (valid value from 1 to 127), or select valid
address value by ‘
4‘, ‘3‘ keys and press ‘ENT’.
2.2.3.3 Manual external device outputs control
Manual relay or ‘open collector’ type outputs controlling given by sertain programs are
realized as follows.
Type password.
Select ‘MANUAL CONTROL’ menu item by ‘
4’, ‘3’ and
‘ENT’ keys, or press hot key ‘4’.
Select ‘RELAY’ menu item by ‘
4’, ‘3’ and ‘ENT’ keys, or
press hot key ‘1’ for quick transition.
Enter device address (valid value from 1 to 127), or select valid
address value by ‘
4’ and ‘3’ keys and press ‘ENT’.
Enter relay number (valid value from 1 to 127), or select valid
address value by ‘
4’ and ‘3’ keys and press ‘ENT’.
Enter relay command number (valid value from 1 to 127), or
select valid address value by ‘
4’ and ‘3’ keys and press
‘ENT’.
Presented control programs:
0-
return initial state;
1-
‘ON’;
2-
‘OFF’;
3-
‘ON’ for a time given when the device relay output being configured;
RELAY #:_
COMMAND #:_
ENTER CODE:_
v2 DISARM
v22 DISARM GROUP
v2 DISARM
v23 DISARM ALL
ENTER CODE:_
ENTER CODE:_
v4 MANUAL CONTROL
ADDRESS:_
v41 RELAY
ADDRESS:_
ADDRESS:_
ADDRESS:_
v3 ALARM RESET
