VEHICLE MODEL QUEST
TM
MAX QUEST
TM
MAX XT
ELECTRICAL
Magneto generator make and type Denso, 400 W @ 6000 RPM
Ignition type CDI (Capacitor Discharge Ignition)
Ignition timing Not adjustable
Engine RPM limiter 7400 RPM (any gear in forward)
Vehicle speed limiter 15 km/h (9 MPH) in reverse
Spark plug make and type NGK DCPR8E
Number of spark plug 1
Spark plug gap 0.6 to 0.7 mm (.024 to .027 in)
Battery 12 V, 19 Ah – electrolyte type battery
Starting system
Electric start.
Start on P, R, N, H, L position
(with brakes apply)
Headlamp 2 x 30 W
Taillight 8/27 W
Pilot lamp cluster LEDS, 0.7 V approx.
FUSES
Location no. 1 (spare 15A) N.A.
Location no. 2 (spare 15A) N.A.
Location no. 3 (accessories) 15 A (power outlet and auxiliary supply)
Location no. 4 (fan) 15 A
Location no. 5 (main) 20 A
Location no. 6 (charging system) 30 A
DRIVE TRAIN
Front differential
Shaft driven/single auto-lock differential
(shear pump)
Rear axle Shaft driven/solid axle
SUSPENSION
Front
Type Independent suspension — double A-arm
Travel 178 mm (7 in)
Rear
Type Rigid swing-arm
Travel 191 mm (7.5 in)
TIRES
Pressure
Up to 272 kg
(600 lb)
Front
35 kPa (5 PSI) minimum,
48 kPa (7 PSI) maximum
Rear
35 kPa (5 PSI) minimum,
48 kPa (7 PSI) maximum
Size
Front 25 x 8 – 12
Rear 25 x 11 – 12
