148
VEHICLE MODEL QUEST
TM
MAX QUEST
TM
MAX XT
WHEELS
Size
Front 12 x 6.5
Rear 12 x 8
Wheel nut torque 75 N•m (55 lbf•ft)
BRAKES
Front Hydraulic, 2 drilled discs
Rear Hydraulic, 1 drilled disc
Parking
Park through transmission.
LH brake lever includes a lock
LOADING CAPACITY
Front rack 40 kg (90 lb) includes front storage tray
Rear rack 80 kg (175 lb) includes tongue load
Console 5 kg (11 lb)
Total vehicle load allowed
272 kg (600 lb) includes operator and
passenger, all other loads and added
accessories (estimate)
GVWR (Gross Vehicle Weight Rating) 646 kg (1420 lb)
Towing capacity 500 kg (1100 lb)
Tongue capacity 14 kg (30 lb) included with rear rack
Front storage tray 10 kg (22 lb) included with front rack
DIMENSIONS
Dry mass 363 kg (798 lb)
Overall length 2.33 m (92 in) 2.37 m (93 in)
Overall width 1.20 m (47 in)
Overall height 1.33 m (52 in)
Seat height 945 mm (37 in)
Wheel base 1.55 mm (61 in)
Wheel track
Front 992 mm (39 in)
Rear 940 mm (37 in)
Turning radius 2.36 mm (93 in)
Ground clearance
Front and
under engine
244 mm (9.6 in)
Rear axle 188 mm (7.4 in)
Weight distribution (front/rear) 49/51%
