VEHICLE MODEL TRAXTER
®
MAX TRAXTER
®
MAX XT
ELECTRICAL
Magneto generator make and type Denso, 400 W @ 6000 RPM
Ignition type IDI (Inductive Discharge Ignition)
Ignition timing Not adjustable
Engine RPM limiter 7700 RPM (any gear in forward)
Vehicle speed limiter 15 km/h (9 MPH) in reverse
Spark plug make and type NGK DR8EA
Number of spark plug 2
Spark plug gap 0.6 to 0.7 mm (.024 to .027 in)
Battery 12 V, 19 Ah – electrolyte type battery
Starting system
Electric start and manual rewind starter.
Start in any gear (with brake applied)
Headlight 2 x 55 W, H4703
Taillight 8/27 W, 1157
Pilot lamp cluster LEDS, 0.7 V approx.
FUSES
Ignition (no. 1) 15 A
Accessories (no. 2) 15 A (power outlet and auxiliary supply)
Solenoids (no. 3) 15 A
Fan (no. 4) 15 A
MPEM (Multi-Purpose Electronic
Module) (no. 5)
20 A
Charging system (no. 6) 30 A
DRIVE TRAIN
Front differential
Shaft driven/single auto-lock differential
(shear pump)
Rear axle Shaft driven/solid axle
Turning radius 2.36 mm (93 in)
SUSPENSION
Front
Type Independent suspension — double A-arm
Travel 178 mm (7 in)
Rear
Type Rigid swing-arm
Travel 190.5 mm (7.5 in)
TIRES
Pressure
Up to 290 kg
(640 lb)
Front
35 kPa (5 PSI) minimum,
48 kPa (7 PSI) maximum
Rear
35 kPa (5 PSI) minimum,
48 kPa (7 PSI) maximum
Size
Front 25 x 8 – 12 TRAILWOLF
Rear 26 x 10 – 12 TRAILWOLF
