152
VEHICLE MODEL TRAXTER
®
MAX TRAXTER
®
MAX XT
WHEELS
Size
Front 12 x 6.5
Rear 12 x 8
Wheel nut torque 75 N•m (55 lbf•ft)
BRAKES
Front Hydraulic, 2 drilled discs
Rear Hydraulic, 1 drilled disc
Parking
Park through transmission.
LH brake lever includes a lock
LOADING CAPACITY
Front rack 40 kg (90 lb) includes front storage tray
Rear rack 80 kg (175 lb) includes tongue load
Total vehicle load allowed
290 kg (640 lb) includes operator and
passenger, all other loads and added
accessories (estimate)
GVWR (Gross Vehicle Weight Rating) 682 kg (1500 lb)
Towing capacity 500 kg (1100 lb)
Tongue capacity 14 kg (30 lb) included with rear rack
Front storage tray 10 kg (22 lb) included with front rack
DIMENSIONS
Dry mass 361 kg (795 lb)
Overall length 2.34 m (92 in)
Overall width 1.20 m (47 in)
Overall height 1.33 m (52 in)
Seat height 945 mm (37 in)
Wheel base 1.55 m (61 in)
Wheel track
Front 992 mm (39 in)
Rear 940 mm (37 in)
Ground clearance
Front and
under engine
244 mm (9.6 in)
Rear axle 188 mm (7.4 in)
Weight distribution (front/rear) 47/53%
vmo2004_011b_5_maintenance.fm Page 152 Thursday, May 29, 2003 11:06 AM
