Actual Values of the Machine
No.
Description
Unit
Display range
Chapter
235 Flux-forming voltage V 0.0 ... U
FIN
19.2
236 Torque-forming voltage V 0.0 ... U
FIN
19.2
238
Flux value
%
0.0 ... 100.0
19.2
239
Reactive current
A
0.0 ... I
max
19.2
240
Actual speed
1/min
0 ... 60000
19.2
241
Actual frequency
Hz
0.0 ... 999.99
19.2
Actual Values of the System
242 Actual System Value Hz 0.0 ... 999.99
19.4.1
Actual Values of the Frequency Inverter
243
Digital inputs (Hardware)
-
00 ... 255
19.1
244 Working hours counter h 99999
19.1
245 Operation hours counter h 99999
19.1
249 Active data set - 1 ... 4
19.1
250 Digital inputs - 00 ... 255
19.1
251
Analog input MFI1A
%
± 100.00
19.1
252 Repetition Frequency Input Hz 0.0 ... 999.99
19.1
254 Digital Outputs - 00 ... 255
19.1
255
Heat sink temperature
deg.C
0 ... T
kmax
19.1
256
Inside temperature
deg.C
0 ... T
imax
19.1
257
Analog output MFO1A
V
0.0 ... 24.0
19.1
258
PWM-Input
%
0.00 … 100.00
19.1
259
Current error
-
FXXXX
19.1
269
Warnings
-
AXXXX
19.1
273 Application Warnings - AXXXX
19.1
275 Controller Status - CXXXX
19.1
277 STO Status - XXXX
19.1
278 Frequency MFO1F Hz 0.00 ... f
max
19.1
Actual Values of the System
285
Volumetric flow
m3/h
0 ... 99999
19.4.2
286 Pressure kPa 0.0 ... 999.9
19.4.2
Actual value memory
287
Peak value Vdc
V
0.0 ... U
dmax
19.3
288
Average value Vdc
V
0.0 ... U
dmax
19.3
289
Peak value heat sink temp.
deg.C
0 ... T
kmax
19.3
290
Average value heat sink temp.
deg.C
0 ... T
kmax
19.3
291 Peak Value Inside Temperature deg.C 0 ... T
imax
19.3
292 Average Value Inside Temperature deg.C 0 ... T
imax
19.3
293 Peak Value Irms A 0.0 ... o ⋅ I
FIN
19.3
294 Average Value Irms A 0.0 ... o ⋅ I
FIN
19.3
295
Peak value active power pos.
kW
0.0 ... o⋅P
FIN
19.3
296
Peak value active power neg.
kW
0.0 ... o⋅P
FIN
19.3
297
Average value active power
kW
0.0 ... o⋅P
FIN
19.3
301
Energy positive
kWh
0 ... 99999
19.3
302
Energy negative
kWh
0 ... 99999
19.3
276 Operating Instructions ACU 06/13
