8.5 Set-up via the Communication Interface
Parameter-setting and commissioning of the frequency inverter via one of the op-
tional communication interfaces include the plausibility check and the parameter
identification functions. The parameters can be adjusted by qualified users. The pa-
rameter selection during the guided commissioning procedure includes the basic pa-
rameters. These are based on standard applications of the corresponding configura-
tion and are therefore useful for commissioning.
WARNING
Parameter settings may only be changed by qualified staff. Before starting the
commissioning process, read the documentation carefully and comply with the safe-
ty instructions.
The parameter SETUP Selection 796 defines the function which is carried out direct-
ly after the selection (if controller enabling signal is present
at digital inputs
S1IND/STOA and S7IND/STOB). The operation modes include functions which are
also carried out automatically one after the other during the guided commission
ing
procedure.
SETUP Selection 796
Function
0 - Clear Status
The auto set-up routine does not perform a func-
tion.
1 - Continue
The warning message is acknowledged and the
auto set-up routine is continued.
2 - Abort
The auto set-up routine is stopped and a RESET of
the frequency inverter is performed.
10 - Complete Setup, DS0
The auto set-up routine is performed in data set 0
and the parameter values are stored in all of the
four data sets identically.
11 -
Auto set-up complete,
DS1
The parameter values of the auto set-up are stored
in data set 1.
12 -
Auto set-up complete,
DS2
The parameter values of the auto set-up are stored
in data set 2.
13 -
Auto set-up complete,
DS3
The parameter values of the auto set-up are stored
in data set 3.
14 -
Auto set-up complete,
DS4
The parameter values of the auto set-up are stored
in data set 4.
20 - Check Machine Data, DS0
The auto set-up routine checks the rated motor
parameters in the four data sets.
21 -
Plaus. contr. motor data,
DS1
The rated motor parameters in data set 1 are
checked for plausibility.
22 -
Plaus. contr. motor data,
DS2
The rated motor parameters in data set 2 are
checked for plausibility.
23 -
Plaus. contr. motor data,
DS3
The rated motor parameters in data set 3 are
checked for plausibility.
24 -
Plaus. contr. motor data,
DS4
The rated motor parameters in data set 4 are
checked for plausibility.
30 -
Calculation and Para-
Ident., DS0
The auto set-up routine determines extended mo-
tor data via the parameter identification feature,
calculates dependent parameters and stores the
parameter values in all of the four data sets identi-
cally.
31 - Calc. and para ident., DS1
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 1.
32 - Calc. and para ident., DS2
Additional motor data are measured, dependent
parameters are calculated and the parameter val-
ues are saved in data set 2.
116 Operating Instructions ACU 06/13
