Activation via communication module CM
Activation of the control unit through a communication connection is possible only if
the frequency inverter is fitted with an optional communication module CM, and com-
munication takes place via this module. The control unit must be connected to the
frequency inverter.
• Establish connection to frequency inverter.
• Start communication and select parameter Program(ming) 34 via the communi-
cation interface.
• Via the communication interface enter value 111 in parameter Program(ming)
34 and confirm this value.
• Via the communication interface enter value 123 in parameter Program(ming)
34 and confirm this value.
The frequency inverter is re-initialized. The display of the control unit reads "rE-
SEt". After that, the unit is initialized.
7.6.2 Data transfer
In order to transmit a file from the control unit to the frequency inverter, proceed as
follows:
• Connect control unit KP 500 to the frequency inverter.
After initialization, the data sources available for transmission are displayed.
• Use the arrow keys to select the data source (Src. Fy) for the transmission to the
frequency inverter.
The files stored in the control unit are available as data sources.
The files stored in the control unit contain all information and parameters stored ac-
cording to the selected copy function ALL or Act (see Chapter "Copy Menu“) in the
control unit.
• Confirm your selection by pressing the ENT key.
The copy process is started. While the copy operation is in process, COPY
and,
as a progress indicator the number of the currently processed parameter will be
displayed.
As soon as the copy operation is complete, the control unit will be re-initialized.
96 Operating Instructions ACU 06/13
