BONFIGLIOLI Active Cube Applications Manual

•
6 Overview of sources
The output values of the spindle function modules are available at the following sources:
Frequency value [s
-1
]
Q.441 –
Actual Speed
Q.443 – Speed Sensor 2
Boolean values
Q.282 -
Target Position Reached
Q.296 - Position (Error)
7 Actual values
Actual value parameters
No.
Description
Unit
Chapter
225
Rotor Flux
%
4.4.3
805
Position of Axle
Degrees
5.3.5
40 ACU Spindle Applications 11/13
