Borger Classic FL 776 - Product Description

3 Product Description
3.1 Construction of the Börger machine
1 Pump chamber
2 Intermediate chamber
3 Gear unit
1 Quick-release cover
2 Pump casing
2.1 Connection flange (inlet, outlet)
3 Rotors
4 Timing gear
4.1 Oil sight glass
4.2 Breather, oil filler for gear unit
4.3 Oil drain for gear unit
4.4 Two shafts with parallel axes; drive shaft can optionally be at
position 0 or 1
5 Shaft seal on pump chamber
6 Intermediate chamber (quench)
6.1 Intermediate chamber fill hole
6.2 Drain from intermediate chamber
6.3 Breather
Components:
Construction:
Product Description
BA-Classic FL_en-US, 03.05.2018 www.boerger.de / www.boerger.com 37
