Base frame
Dimensions approx. [mm] approx. [inch]
A 1225 48.23
B 110 4.33
C 590 23.23
D 1135 44.69
E 45 1.77
G 18 0.71
Weight approx. [kg] approx. [lb]
approx. 85 187
The dimensions can be found in the specific dimensional drawing
created for the order
. The dimensions and weights of the drive and
gear unit etc. can be found in the corresponding manufacturer’s
documentation. The weight of the complete unit is specified in the
data sheet.
3.3.2 Performance data and maximum loads
The specification of the pump output for which the rotary lobe
pump was actually configured can be found in the data sheet.
The geometric displacement volume of the pump series is as fol-
lows:
Base frame
Complete unit
Rotary lobe pump
Product Description
BA-Classic FL_en-US, 03.05.2018www.boerger.de / www.boerger.com52
