9.5 Parallel keys
The following parallel key lengths must be adhered to and
checked.
NOTICE!
Risk of material damage when operated with an incorrect or
damaged parallel key!
Imprecise parallel key lengths can lead to misalignment of the
rotating holding bush and can cause mechanical damage to the
Börger machine or to the complete unit.
Version Parallel key dimensions [mm] [inch] (approx.)
for rotors
with integrated cover disk
for rotors
with separate cover disk
For Fusion rotors
(special version)
FL 518
— 14 x 9 x 82 mm
—
0.55 x 0.35 x 3.23 "
— 14 x 9 x 93 mm
— 0.55 x 0.35 x 3.66 "
— 14 x 9 x 207 mm
— (93+114 mm)
— 0.55 x 0.35 x 8.15 "
— (3.66+4.49 ")
FL 776
— 14 x 9 x 146 mm
—
(93+53 mm)
— 0.55 x 0.35 x 5.75 "
— (3.66+2.09 ")
— 14 x 9 x 156 mm
— (93+63 mm)
— 0.55 x 0.35 x 6.14 "
— (3.66+2.48 ")
— 14 x 9 x 218 mm
— (93+125 mm)
— 0.55 x 0.35 x 8.58 "
— (3.66+4.92 ")
FL 1036
— 14 x 9 x 207 mm
—
(93+144 mm)
— 0.55 x 0.35 x 8.15 "
— (3.66+4.49 ")
— 14 x 9 x 218 mm
— (93+125 mm)
— 0.55 x 0.35 x 8.58 "
— (3.66+4.92 ")
— 14 x 9 x 223 mm
— (93+70+60 mm)
— 0.55 x 0.35 x 8.78 "
— (3.66+2.76+2.36 ")
9.6 Checklist for commissioning
This checklist can be used as an additional aid when commis-
sioning a Börger machine. It is not a substitute for careful reading
of the operating manual before commissioning the unit.
