NOTE!
The nuts underneath the base frame must be accessible with a
wrench from the front and back. If realignment is required or the
machine is reinstalled on the base frame (e.g. following repairs or
replacement), then it must be possible to hold the nuts in place
with a wrench.
Only set the base frame in concrete if a suitable special base
frame has been delivered as agreed upon in advance.
Personnel:
n
Mechanics
Protective equipment:
n
Occupational safety clothing, chemical
resistant
n
Safety shoes
n
Safety gloves, chemical-resistant
n
Safety goggles
Special tool:
n
T
ools, general
n
Hammer drill
— Read and follow the safety instructions detailed in
Ä
Chapter
2.12 “Safety instructions for maintenance and rectifying mal-
functions” on page 30.
— To the extent necessary, amply secure the surrounding area
when performing installation. Cordon off the working area with
a red and white safety chain and a warning sign.
1. Position the base frame without subjecting it to stress.
2. Compensate for any unevenness in the floor
, e.g. by using
washers or shims.
3. Install the base frame onto the reinforced surface without
subjecting it to stress, e.g. using four suitable anchor bolts
and appropriate resin capsules or four other safe fixing sys-
tems suitable for the surface and the application.
Versions with base frames
Transportation, Storage and Installation
BA-Classic FL_en-US, 03.05.2018 www.boerger.de / www.boerger.com 67
