Borri E2001 COMPACT - Page 44

Front panel AC-UPS GD 128x64
26 OMX76014 Rev. A
Status
S10
SLAVE
Description
In parallel configuration the unit is the SLAVE.
Operating
condition
The SLAVE status is enabled when it is connected to another
rectifier with the share current enabled.
Status
S11
PARALLEL OFF
Description
The current allocation algorithm is disabled
Operating
condition
In the MASTER unit, this condition is alternative to S9-MASTER
when the rectifiers are separated.
In the SLAVE unit, this condition is alternative to S10-SLAVE when
the rectifiers are separated or when the output current is too low to
be shared.
Status
S12
RECTIFIER SHARE OK
Description
Current share algorithm enabled and working.
Operating
condition
This condition is enabled when the output current of the rectifier is
correctly shared among the rectifiers.
Status
S13
BOOST INHIBITION
Description
The boost function is inhibited.
Operating
condition
The rectifier does not allow activation of the rapid charge.
Status
S14
INVERTER ON
Description
Inverter on.
Operating
condition
The inverter is on.
Status
S15
INVERTER OK
Description
The inverter is working properly.
Operating
condition
The inverter has no active system alarm (e.g. A37 overload, etc.).
Status
S16
INVERTER FEEDS LOAD
Description
The inverter feeds the load.
Operating
condition
The inverter is running, the inverter static is closed and the output
switch is closed. The inverter feeds the load.
Status
S17
INVERTER SYNCHRONISED
Description
The inverter is synchronised with the mains.
Operating
condition
The bypass mains is available and in tolerance. The inverter is on
and synchronised with the bypass.
