Front panel AC-UPS GD 128x64
OMX76014 Rev. A 27
Status
S18
SLAVE SYNCHRONISED
Description
The inverter is synchronised with the MASTER.
Operating
condition
Status active only in configurations with the inverter parallel and
only on SLAVE machines. The inverter is synchronised with the
MASTER output.
Status
S19
BYPASS OK
Description
The bypass mains is available and in tolerance.
Operating
condition
The bypass mains is available and in tolerance.
Status
S20
BYPASS FEEDS LOAD
Description
The load is powered by the bypass.
Operating
condition
The bypass network is available and in tolerance, the bypass static
is closed and the switch is closed. The load is powered by the
bypass mains.
