2.6 System overview
EOL
LSN improved/classic
1
2
Figure2.5: System overview with periphery
Position Description
1 LSN loop (classic or improved version)
2 Conventional stub with EOL resistor or EOL module
(optional: conventional loop)
The tables below list the various product groups with all compatible peripheral devices.
The devices approved for connection to the CZM 0004 A Conventional Module or the
FLM-420/4‑CON Conventional Interface Module can be found in the relevant compatibility lists
at www.boschsecurity.com.
