64 en | System limits AVENAR panel
2022-07 | 5.0 | F.01U.378.910
System manual
Bosch Sicherheitssysteme GmbH
Module Device Max. number Further information
FMF-ADP-TTY
FMF-ADP-FBF
FMF-FAT 4
FMF-FBF-FAT 4
FLM-420-I8R1-S FCS-LHD-2EN 1 Altogether only 200 LSN devices
including max. 2 EOL modules on
the same LSN bus
No pre-alarm
LSN 0300 A
LSN 1500 A
FLM-420-RLE-S 8 Max. number is valid for fire
extinguishing systems
FNX-425U 84/127 Up to 84 elements per loop
Up to 127 elements per loop if
operated without detector
FWI-270 10
Any manual call point 21
FLM-420-EOL2W-W
FLM-420-EOL4W
10
FWI-270 FDOOT271-O
FDM273-O
FDM275-O
30
NZM 0002 A SOL-LX 11 1 Hz
18 0.5 Hz
PA 5 2
PA 10-SSM 1
7.4 Power loss of panel components
i
Notice!
Power loss of components (typical)
In the data sheet of the system you will find more detailed information on the listed typical
power loss values.
Component Power loss
ANI 0016 A 0.62W (all LEDs lit)
BCM‑0000‑B – 0.96W (controller + green LED lit)
– 1.44W (per AUX with 1.06A load)
CZM 0004 A – 1.65W (for a line with 100mA load)
– 3.36W (for 4 lines with 100mA load each)
ENO 0000 B – 1.44W (1 relay activated)
– 7.80W (4 relays activated + key deposit heating
active)
FPE-2000-PPC max. 10W
