AVENAR panel System limits | en 63
Bosch Sicherheitssysteme GmbH
System manual
2022-07 | 5.0 | F.01U.378.910
Configuration limits per fire panel (FSP-5000-RPS) Max. number
Exportable objects including counters in the entire panel cluster
(without pre-defined system counters)
2000
Importable objects including counters (without pre-defined system
counters)
2000
Automatic connections to remote keypad 3
Blocks of State-Dependent Rules (depending on what kind of
activations are possible)
8
Maximum number of rules within a block 254
Number of functional modules Max. number
ANI 0016 A 4
BCM-0000-B 5
CZM 0004 A 4
ENO 0000 B 4
FPE-5000-UGM 4
IOP 0008 A 4
IOS 0020 A 4
IOS 0232 A 4
LSN 0300 A 4
LSN 1500 A 0
NZM 0002 A 4
RMH 0002 A 4
RML 0008 A 4
7.3 Maximum number of devices per functional module or interface
module
Module Device Max. number Further information
CZM 0004 A
FLM-420/4‑CON
016519 1
016589 1
FLM-420-NAC-D PA 5 3 Used with FPP-3000
2 Used with FPP-5000/BCM-0000-B
PA 10-SSM 2 Used with FPP-3000
1 Used with FPP-5000/BCM-0000-B
PY X-M-10-SSM 1 Used with FPP-3000/FPP-5000/
BCM-0000-B
SOL-LX 10
