Bosch AVENAR panel - Table of Contents

AVENAR panel Table of contents | en 3
Bosch Sicherheitssysteme GmbH
System manual
2022-07 | 5.0 | F.01U.378.910
Table of contents
1
Safety 5
2
AVENAR panel series 7
2.1 Product description 7
2.2 Panel controller 11
2.3 Remote keypad 15
2.4 Housings for frame Installation 17
2.5 Housings for wall mounting 20
2.6 System overview 22
2.7 Networking 25
2.8 Connection to BIS 25
2.9 Connection to a voice alarm system 26
3
Planning 28
3.1 LSN modules 28
3.2 Detection points 29
3.3 Address setting 30
3.4 Topologies in Local Security Network 31
3.5 Failure handling in Local Security Network 33
3.6 Redundancy 34
3.6.1 AVENAR panel 8000 with panel redundancy 34
3.6.2 Remote keypad as redundant panel controller 34
3.7 Achievable cable length with LSN 0300 A 35
3.8 Achievable cable length with LSN 1500 A 37
3.9 Configuration with BCM-0000-B modules 40
3.10 Protective earth and equipotential bonding 44
4
Installation 45
4.1 General information 45
4.2 Installation sequence 46
4.3 Installation of CPH 0006 A, fully assembled panel 47
4.4 Installation of HCP 0006 A, fully assembled panel 48
4.5 Extended line monitoring (VdS 2540, VdS 2543) 48
4.6 FPP‑5000 External Power Supply Unit Kit 24 V/6 A 49
5
Commissioning 51
5.1 Functional test 51
5.1.1 Testing the power supply 52
5.1.2 Testing the Conventional and LSN Functions 52
5.1.3 Testing the Addressing/Activation 52
5.2 Panel controller firmware 52
5.3 Storing trace files on a memory card 54
6
Maintenance and service 56
6.1 Replacement of FPA panel controller 57
7
System limits 60
7.1 System limits AVENAR panel 8000 60
7.2 System limits AVENAR panel 2000 61
7.3 Maximum number of devices per functional module or interface module 63
7.4 Power loss of panel components 64
7.5 FPP‑5000 External Power Supply Unit Kit 24 V/6 A 65
8
Appendix 66
8.1 Options with requirements under EN 54‑2:1997/A1:2006 66
