4 Installation
Consider the general information and follow the rough installation sequence. Subsequently
you find two specific installation sequences:
– CPH 0006 A, fully configured panel
– HCP 0006 A, fully configured panel
For information on the installation of each component, refer to the Installation guide, which is
included in the delivery and also available at www.boschsecurity.com.
4.1 General information
!
Warning!
Live components and stripped cable! Risk of injury from electric shock. The system must be
current-free during connection work.
!
Warning!
Electrostatic discharge.
The standard precautions for CMOS technology must be taken when handling PC boards.
!
Warning!
Risk of overheating
Bosch provides no front door for this system. You are not allowed to operate the system with
a front door. Otherwise, the system can overheat, because the air vents are blocked.
– The fire panel may only be installed and commissioned by trained specialist personnel.
– Only use installation materials recommended by Bosch. Otherwise, interference
resistance cannot be guaranteed.
– Connection conditions set down by the regional authorities and institutions (police, fire
service) must be observed.
Environmental Conditions
– Assembly and operation of the fire panel must be carried out in a clean and dry indoor
location.
– Permissible relative humidity: max. 95% at 25°C, non-condensing
– To ensure optimum battery service life, the panel should only be operated at sites with
normal room temperatures.
– Do not operate devices showing condensation.
Positioning
– Operating and display elements should be positioned at eye level.
The distance between the upper edge of the housing and the center of the panel
controller display is around 11cm. For example, if the eye level required is 164cm, the
housing upper edge installation dimension is 175cm.
– For frame installation housings, a clearance of at least 230mm is required to the right of
the last housing to swivel out the installed housing (e.g. for connection, maintenance or
service).
– Sufficient space should be left below and next to the panel for any possible extensions,
e.g. for an additional power supply or an extension housing.
