68 en | Appendix AVENAR panel
2022-07 | 5.0 | F.01U.378.910
System manual
Bosch Sicherheitssysteme GmbH
Mounting Frames
Designation Installation
manual ID
FBH0000A Mounting Frame Large 4998153998
FHS0000A Mounting Frame Large with Distributor Rail 4998154018
FMH0000A Mounting Frame Medium 4998153999
FSH0000A Mounting Frame Small 4998154000
48cm (19”) Installation Kits for Frame Installation Housing
Designation Installation
manual ID
FRB0019A Installation kit, large, 15 height units 4998154015_610
FRM0019A Installation kit, medium, 12 height units 4998154017_610
FRS0019A Installation kit, small, 6 height units F01U003352_610
8.3.2 Wall mounting housings and installation kits
Panel Housings for Wall Mounting
Designation Installation
manual ID
HBC0010A Modular Panel Housing for 10 Modules 4998153994
HCP0006A Modular Panel Housing for 6 Modules 4998153994
Extension Housings for Wall Mounting
Designation Installation
manual ID
DIB0000A Distribution Box F01U003105_610
HBE0012A Modular Extension Housing for 12 Modules 4998153994
PSB0004A Power Supply 4998154010
PSS0002A Power Supply Small, Frame Installation 4998154010
48cm (19”) Installation Kit for Wall Mounting Housing
Designation Installation
manual ID
FRK0019A Installation kit F01U005045
8.3.3 Accessories for housing
Mounting Plates/Installation Accessories
Designation Installation
manual ID
FPO‑5000‑EB Earth Bar F01U005061
HMP0003A Mounting Plate for Mounting Frame F01U003791
