Product Information
Climate 3000i – 6721823680 (2022/10)
56
2Product Information
2.1 Declaration of conformity
The design and operating characteristics of this product comply with the
European and national requirements.
The CE marking declares that the product complies with all the
applicable EU legislation, which is stipulated by attaching this
marking.
The complete text of the Declaration of Conformity is available on the
Internet: worcester-bosch.co.uk.
2.2 Scope of delivery
Key to Fig. 1:
[1] Outdoor unit (filled with refrigerant)
[2] Indoor unit (filled with nitrogen)
[3] Cold catalyst filter
[4] Drainage elbow with gasket (for outdoor unit with floor or wall
mounting bracket)
[5] Remote control
[6] Remote control holder with fixing screw
[7] Fixing materials (5 screws and 5 wall plugs)
[8] Set of printed documents for product documentation
[9] 5-core communication cable (optional accessory)
[10] 4 anti-vibration couplings for the outdoor unit
2.3 Product dimensions and minimum clearances
2.3.1 Indoor unit and outdoor unit
Figures 2 to 4.
2.3.2 Refrigerant pipes
Key to Fig. 5:
[1] Gas-side pipe
[2] Liquid-side pipe
[3] Siphon-shaped elbow as oil separator
If the outdoor unit is positioned higher than the indoor unit, install a
siphon-shaped elbow on the gas side after no more than 6 m and every
6 m thereafter ( Fig. 5, [1]).
▶ Observe maximum pipe length and maximum difference in height
between indoor unit and outdoor unit.
Table 2 Pipe length and difference in height
Table 3 Pipe diameter depending on appliance type
Table 4 Alternative pipe diameter
Table 5
2.4 Information on refrigerant
This device contains fluorinated greenhouse gases as refrigerant.
The device is hermetically sealed. You will find the information on the
refrigerant according to the Regulation (EU) No 517/2014 on
fluorinated greenhouse gases in the operating instructions of the device.
Information for the installer: If you refill refrigerant, enter the additional
charge size and the total charge size of the refrigerant in the table
“information on refrigerant” of the operating instructions.
Maximum pipe
length
1)
[m]
1) Gas side or liquid side
Maximum difference
in height
2)
[m]
2) Measured from bottom edge to bottom edge.
CL3000i 26 E ≤ 25 ≤ 10
CL3000i 35 E ≤ 25 ≤ 10
CL3000i 53 E ≤ 30 ≤ 20
CL3000i 70 E ≤ 50 ≤ 25
Pipe size
Unit type Liquid side [mm] Gas side [mm]
CL3000i 26 E 6.35 (1/4") 9.53 (3/8")
CL3000i 35 E 6.35 (1/4") 9.53 (3/8")
CL3000i 53 E 6.35 (1/4") 12.7 (1/2")
CL3000i 70 E 9.53 (3/8") 15.9 (5/8")
Pipe diameter [mm] Alternative pipe diameter [mm]
6.35 (1/4") 6
9.53 (3/8") 10
12.7 (1/2") 12
15.9 (5/8") 16
Specification of the pipes
Min. piping length 3 m
Standard piping length 5 m
Additional refrigerant if the pipe length
exceeds 5 m (liquid side)
With Ø 6.35 mm (1/4"):
12 g/m
With Ø 9.53 mm (3/8"):
24 g/m
Pipe thickness with 6.35 mm to 12.7 mm
pipe diameter
≥0.8mm
Pipe thickness with 15.9 mm pipe
diameter
≥1.0mm
Thickness of heat insulation ≥ 6 mm
Material of heat insulation Polyethylene foam
