Programming to Set Up Central Station Reporting
Notice!
In order to use the D9412GV4/D7412GV4 v2.00 Modem4 reporting format, the Central
Station receiver must be updated with the latest software for proper functionality and
operation.
Notice!
You can program these items using RPS (version 5.15 or greater) and the steps listed below.
You can also use keypad programming (refer to the D9412GV4/D7412GV4 v2.00 Program Entry
Guide).
Basic Telephone Set Up in RPS
1. Go to PANEL WIDE PARAMETERS→ Phone and Phone Parameters.
2. Enter the primary telephone number in the Phone 1 field.
3. If a secondary telephone number is required, enter it in the Phone 2 field.
4. Go to Panel Wide Parameters→Communicator→Route Group 1.
5. Enter Phone 1 in the Primary Device field.
6. If a secondary telephone is required, enter Phone 2 in the Backup Device field.
Basic Internet Protocol (IP)
1. Go to PANEL WIDE PARAMETERS→Communicator→Route Group 1 Primary Device.
2. Select SDI Address 88 Path 1.
3. Go to PANEL WIDE PARAMETERS→SDI RPS/Enhanced Comm→Enable Enhanced
Communications to Yes.
4. Go to PANEL WIDE PARAMETER→Enhanced Communications.
5. Select or enter the following values:
Notice!
Enhanced Communications settings usually follow the recommendations of Central Stations’
staff. If using a B426, B420, ITS-DX4020, or ITS-DX4020-G for communication, refer to the
appropriate Installation and Operation Guide for more information.
Parameter Value
Enable Enhanced Communication YES
Path 1 Network Address IP or Network address of Central Station
receiver
Path 1 Port Number Port Number of Central Station receiver
Path 1 Poll Rate (seconds)
1
Poll rate recommended by Central Station
Path 1 ACK Wait Time 13 sec (default setting)
Path 1 Retry Count 5 (default setting)
1
If the control panel is programmed to send a heartbeat poll to the Central Station, a rate of
75 sec maintains the virtual link in most network configurations.
5
5.1
5.2
14 en | Programming to Set Up Central Station Reporting Control Panel
2014.05 | 05 | F.01U.265.463 Quick Reference Guide Bosch Security Systems, Inc.
