DIVAR 2000 / DIVAR 3000 / DIVAR
26 en | Hardware setup
5000
DIVAR 2000/3000
1, 2, 3， 4 Alarm inputs: max. 4. The alarm becomes active at low voltage. Max.
input voltage 15 VDC.
NO1 C1， Two groups of normal open activation outputs (on/off button).
NO2 C2，
G Ground cable.
DIVAR 5000
1， 2， 3， 4， 5，
6， 7， 8， 9， 10，
11， 12， 13， 14，
15， 16
Alarm inputs: max. 16. The alarm becomes active at low voltage.
NO1 C1,
NO2 C2,
NO3 C3,
NO4 C4,
NO5 C5
Groups of normal open activation alarm outputs (on/off button).
CTRL +12V Control power output. Always close the device power to cancel the
alarm.
+12V External power output. Need the peripheral equipment to provide
+12 V power (below 500 mA).
G Ground cable.
