Bosch DIVAR 2000 User Manual

7.1.3
DIVAR 2000 / DIVAR 3000 / DIVAR
Operation | en 47
5000
Play Next In playback mode, playback the next video
In menu setup, scroll down the dropdown list
In text mode or when choosing a camera channel, input
number 8 (only on DIVAR 2000/3000)
Play/Pause
In normal playback, click to pause playback
In pause mode, click to resume playback
In text mode or when choosing a camera channel, input
number 2 (only on DIVAR 2000/3000)
The DIVAR 5000 also has the following buttons
Export
Export the currently selected files to an external device
Sequence
Activate the camera views in a pre-set sequence
Numeric keypad
Switch camera channels
In text mode, enter characters in a field (use the Shift
button to change the input mode)
The front panels also have the following status lights and a USB connector:
Status lights Symbol Function
Channel record 1-16 A channel number is lit if the channel is recording.
For 32-channel units, press <Shift> and hold in for 5 seconds
to show recording status of channels 17 to 32. Release <Shift>
again to return recording status view of channels 1 to 16. This
function only works in ‘Live’ mode, with no menus open.
Hard disk
Is lit if an installed hard disk has an error or is full.
Network
Is lit if a user is connected to the DVR online.
USB port
Connect USB storage device or USB mouse to this port.
Remote control
All functions controlled by the front panel and USB mouse can, alternatively, be accessed
using the supplied remote control.
The IR remote control allows control of up to 999 units without interfering with one another.
An ID number must be chosen on the remote control and in the system (see menu Setting >
General for setting a system ID for each unit).
To set the ID on the remote control:
1. Press the Add button on the remote control.
2. Press a number between 0 and 998 that corresponds to the unit ID you wish to control
(this unit will remain as the default until you select another unit with the Add button).
3. Press the Enter button to set the unit ID.
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com

Bosch DIVAR 2000 Specifications

General

Number of fans	1 fan(s)
Input bandwidth	256 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	128 Mbit/s
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Supported resolutions	3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	720p, 1080p
Video motion detection	Yes
Video formats supported	H.264, H.265, M-JPEG
DC-in jack	No
Disc types supported	DVD, DVD+R, DVD+RW
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Power over Ethernet (PoE) ports quantity	8
HDD capacity	2000 GB
HDD interface	Serial ATA III
Maximum storage capacity	6 TB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Total Power over Ethernet (PoE) budget	115 W
Power over Ethernet (PoE) power per port	25.5 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 93 %
Mobile operating systems supported	Android, iOS
Sustainability certificates	RoHS
Certification	FCC, UL, CE,
Product color	Black

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
