6.6.2
DIVAR 2000 / DIVAR 3000 / DIVAR
Settings | en 43
5000
6.6
6.6.1
Storage
HDD manage
Here you can view and manage the HDD(s) installed in your DVR:
– SATA: shows the current selected hard disk where the system will continuously record,
overwriting the oldest unprotected video on the hard disk with newer video. When an
HDD is working properly, it is shown as O; if an HDD error has occurred, it is shown as X
– E-SATA (only available on the DIVAR 5000): shows the current selected hard disk where
the system will continuously record. If required, press the ESATA button to access a new
status screen where you can detect ESATA connections.
– The various buttons on this screen are described below:
– Slot.: Select a HDD from the dropdown list to manage its settings – see below.
– Mode: Select an HDD mode from the dropdown list:
– Read/Write
– Read-only
– Format: format all data on the HDD – here you will need to enter your password to
confirm the format process
Notice!
System reboot required
You must reboot the system to activate any modifications
The bottom half of the screen shows the current HDD type, status, capacity and the recording
time(s).
Recording
Here you can manage the storage of recordings:
HDD full: assign here what to do when the HDD is full
– Overwrite old recordings starting with the oldest (default)
– Stop recording
Auto delete old files: assign what to do with old files on the storage device
– Overwrite old recordings starting with the oldest (default)
– Stop recording
Main stream recording: assign here how to record the main stream on each individual
channel
– Schedule - record according to the scheduled times set in the tab Schedule
– Forced on - record continuously
– Off - do not record
Sub stream recording: assign here how to record the sub stream on each individual channel
– Schedule - record according to the scheduled times set in the tab Schedule
– Forced on - record continuously
– Off - do not record
Bosch Security Systems Operation Manual 2016.09 | v1.0 | AM18-Q0717
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com

Bosch DIVAR 2000 Specifications

General

Number of fans	1 fan(s)
Input bandwidth	256 Mbit/s
Number of users	128 user(s)
Recording modes	Manual, Schedule, Stop
Output bandwidth	128 Mbit/s
Maximum resolution	3840 x 2160 pixels
Video input channels	16 channels
Supported resolutions	3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video recording modes	720p, 1080p
Video motion detection	Yes
Video formats supported	H.264, H.265, M-JPEG
DC-in jack	No
Disc types supported	DVD, DVD+R, DVD+RW
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	9
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS/DDNS, IP Filter, PPPoE, FTP
Power over Ethernet (PoE) ports quantity	8
HDD capacity	2000 GB
HDD interface	Serial ATA III
Maximum storage capacity	6 TB
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Total Power over Ethernet (PoE) budget	115 W
Power over Ethernet (PoE) power per port	25.5 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 93 %
Mobile operating systems supported	Android, iOS
Sustainability certificates	RoHS
Certification	FCC, UL, CE,
Product color	Black

Weight and Dimensions

Depth	323 mm
Width	375 mm
Height	53 mm
