-9-
1@@5:3&;:;C+;A>&-.81%-C
"!)$%)&
Switch incorporates hole for use with padlock to pre-
vent accidental starting.
(&! )
Elevates or lowers the blade. Also used to tilt the
blade 0 to 45 degrees.
(!
Locks the blade to de sired bevel angle.
(%
Shows the degree the blade is tilted.
%
Supports table saw. Holes are provided in base to
bolt the saw to a workbench or stand. Includes inte-
grated carry and adjustment handles
&*& %! !
Allows you to lock the table extension at desired dis-
tances. Also prevents use of table saw with un-
locked extension.
"'%%&
Allows you to rip smaller pieces of stock with a
greater level of safety.
&*& %!
Provides a larger work surface for wider workpieces.
$"
Exclusive Self-Aligning, Squarelock rip fence can be
easily moved or locked in place by simply raising or
lowering lock handle.
$" %
Shows the distance from the blade to rip fence
through a convenient viewing and magnifying win-
dow. Lower portion of scale can be used up to 10
inches. Upper portion of scale is used for cuts be-
yond 10 inches.
%$&'$%+%&
Consists of three key elements: Adjustable (3 posi-
tion) Riving Knife, Anti-Kickback Device, and Barrier
Guard Device. All of these are part of a modular sys-
tem that requires no tools to assemble or unassem-
ble. This Guard System must always be in place and
working properly for all thru-sawing cuts.
& %$&
Removable for removing or installing blade or other
cutting tools.
D
E
Y
12
13
54
3
8
6
24
10
14
FIG. 1
15
9
11
7
12
