6 Product Specifi cations
6.1 Bosch IDS BVA2.0
BVA024 BVA036 BVA048 BVA060
Cooling Capacity
Nominal Cooling (BTU/h) 24000 34600 47500 54500
Nominal Heating (BTU/h) 24000 34200 48000 56000
Blower
Diameter (mm) 10-5/8" (270) 10-63/64" (279) 10-63/64" (279) 10-63/64" (279)
Width (mm) 8-5/32" (207) 10-43/64" (271) 10-43/64" (271) 10-43/64" (271)
Fan Motor
Horsepower (HP) 1/3 1/2 3/4 3/4
Full Load Amps 2.6 3 4.5 4.5
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (O.D.) 3/8" 3/8" 3/8" 3/8"
Suction Line Size (O.D.) 3/4" 3/4" 7/8" 7/8"
Refrigerant Connection Size
Liquid Line Size (O.D.) 3/8" 3/8" 3/8" 3/8"
Suction Line Size (O.D.) 3/4" 3/4" 7/8" 7/8"
Expansion Device [TXV=Thermal Expansion Valve] TXV
Decibels dB(A)
High Speed 63 65 67 68
Medium Speed 59 62 63 64
Low Speed 55 58 59 60
Electrical Data
Voltage-Phase-Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Minimum Circuit Ampacity ² 3.3 3.8 5.7 5.7
Max. Overcurrent Protection ³ 15 15 15 15
Min / Max Volts 172V/270V
Air Filter
Air Filter Sizes 18" x 20" 18" x 20" 20" x 22" 20" x 22"
Weight
Net Weight (without packaging)(lbs) 119 126 162 170
Gross Weight (including packaging)(lbs) ⁴
132 139 180 188
Dimensions
Unit D x W x H (in.)
21-5/8 x 19-5/8 x 46-1/2 21-5/8 x 19-5/8 x 46-1/2 24 x 22 x 54-1/2 24 x 22 x 54-1/2
Unit D x W x H (in.)(with pallet and packaging)
25-3/8 x 22-5/16 x 52-9/16 25-3/8 x 22-5/16 x 52-9/16 27-11/16 x 24-11/16 x 60-5/8 27-11/16 x 24-11/16 x 60-5/8
Indoor Coil
Net face area-sq.ft. 4.02 4.02 5.99 5.99
Tube diameter 9/32" (7 mm) 9/32" (7 mm) 9/32" (7mm) 9/32" (7mm)
No.of rows 4 4 4 5
Fins per inch 17 17 17 17
Table 5
¹ Tested and rated in accordance with AHRI Standard 210/240.
² Wire size should be determined in accordance with National Electrical Codes;
extensive wire runs will require larger wire sizes.
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as noted.
⁴ Weight shown includes packaging

Bosch IDS 2.0 Specifications

General

Refrigerant	R-410A
Stages	Variable
Voltage	208/230 V
System Type	Air Source Heat Pump
Compressor Type	Inverter-driven
Sound Level	As low as 56 dB
Heating Capacity	Varies by model
Cooling Capacity	Varies by model
Noise Level	45 dB to 60 dB
Operating Temperature Range (Heating)	-20°C to 35°C
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Seasonal Coefficient of Performance (SCOP)	Not Available
