22
|
Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
7.2 Outdoor Unit (BOVA) + Indoor Unit (BVA) – Heating Mode
BOVA 36 + BVA 24 For Heating
Airfl ow
(CFM)
ID
(°F)
OD
(°F)
86 72 67 62 57 52 47 42 37 32 27 22 17 12 7 2 -4
620
60
TC 26.8 26.8 26.8 26.8 26.8 26.7 26.7 26.5 26.5 25.8 25.3 24.3 24.2 22.4 21.4 20.4 18.6
kW 0.90 1.20 1.31 1.44 1.59 1.71 1.86 2.00 2.21 2.26 2.57 2.48 2.41 2.33 2.25 2.19 2.13
70
TC 19.9 19.9 19.9 19.9 19.8 19.8 19.8 19.8 19.7 19.7 19.7 19.7 18.8 17.7 16.9 16.6 15.8
kW 0.63 0.88 0.97 1.06 1.17 1.26 1.37 1.54 1.65 1.76 1.90 2.02 2.12 2.36 2.43 2.35 2.29
75
TC 16.4 16.4 16.3 16.3 16.2 16.2 16.2 16.2 16.2 16.2 16.2 16.2 16.2 16.1 16.1 16.1 15.7
kW 0.61 0.73 0.81 0.88 0.96 1.06 1.16 1.25 1.37 1.48 1.57 1.70 1.81 1.92 2.09 2.28 2.38
80
TC 12.9 12.9 12.9 12.9 12.9 12.9 12.9 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.8 12.7 12.7
kW 0.50 0.59 0.66 0.72 0.80 0.86 0.94 1.00 1.14 1.20 1.29 1.37 1.46 1.59 1.70 1.80 1.95
660
(Low
Stage)
60
TC 27.3 27.3 27.2 27.2 27.2 27.2 27.2 27.0 27.0 25.7 26.2 24.5 24.4 23.2 22.1 21.1 19.5
kW 0.90 1.21 1.31 1.44 1.60 1.71 1.86 2.02 2.23 2.22 2.52 2.44 2.36 2.29 2.22 2.15 2.10
70
TC 20.2 20.2 20.2 20.2 20.2 20.1 20.1 20.1 20.0 20.0 20.1 20.0 19.1 18.0 17.2 16.8 16.0
kW 0.64 0.89 0.96 1.05 1.16 1.25 1.37 1.53 1.65 1.76 1.88 2.03 2.20 2.38 2.39 2.31 2.25
75
TC 16.5 16.5 16.5 16.5 16.5 16.5 16.5 16.5 16.4 16.4 16.4 16.4 16.5 16.3 16.3 16.3 15.6
kW 0.51 0.73 0.79 0.87 0.97 1.05 1.15 1.24 1.36 1.48 1.56 1.70 1.81 1.93 2.10 2.30 2.34
80
TC 13.1 13.1 13.1 13.1 13.1 13.1 13.1 13.0 13.0 13.0 13.0 13.0 13.0 13.0 13.0 12.9 12.9
kW 0.40 0.58 0.64 0.70 0.78 0.84 0.93 1.02 1.13 1.19 1.28 1.36 1.45 1.58 1.70 1.82 1.96
760
60
TC 29.9 29.9 29.9 29.9 29.9 29.8 29.7 29.7 27.8 26.0 26.6 24.8 24.7 23.4 22.3 21.3 19.7
kW 1.04 1.37 1.49 1.61 1.77 1.88 2.06 2.28 2.25 2.18 2.48 2.41 2.34 2.27 2.21 2.14 2.10
70
TC 22.2 22.2 22.2 22.2 22.2 22.1 22.1 22.1 22.0 22.0 22.0 22.0 21.0 19.8 18.9 18.5 17.6
kW 0.74 1.00 1.08 1.18 1.29 1.41 1.57 1.69 1.83 1.93 2.11 2.27 2.46 2.45 2.38 2.30 2.24
75
TC 18.2 18.2 18.2 18.2 18.2 18.2 18.2 18.1 18.1 18.1 18.1 18.1 18.0 18.0 18.0 17.1 15.8
kW 0.60 0.82 0.89 0.97 1.08 1.17 1.27 1.37 1.54 1.63 1.75 1.87 1.99 2.15 2.34 2.40 2.33
80
TC 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.4 14.3 14.2 14.2
kW 0.47 0.66 0.72 0.79 0.87 0.94 1.05 1.13 1.24 1.31 1.41 1.50 1.63 1.74 1.82 2.01 2.17
860
(High
Stage)
60
TC 32.7 32.7 32.7 32.7 32.7 32.4 32.4 30.4 28.2 26.1 26.9 25.0 24.8 23.5 22.5 21.4 19.9
kW 1.19 1.54 1.66 1.80 1.96 2.11 2.30 2.29 2.23 2.17 2.46 2.40 2.34 2.27 2.21 2.15 2.10
70
TC 24.3 24.3 24.3 24.3 24.3 24.2 24.2 24.1 24.1 24.0 24.0 24.0 22.9 21.6 20.6 19.7 18.2
kW 0.84 1.13 1.22 1.32 1.48 1.58 1.73 1.86 2.01 2.14 2.35 2.53 2.52 2.45 2.38 2.31 2.26
75
TC 19.9 19.9 19.9 19.9 19.9 19.9 19.9 19.8 19.8 19.8 19.8 19.7 19.7 19.7 19.0 17.4 16.1
kW 0.69 0.93 1.00 1.09 1.20 1.29 1.41 1.57 1.69 1.79 1.93 2.05 2.20 2.39 2.48 2.40 2.34
80
TC 15.8 15.8 15.8 15.8 15.8 15.8 15.7 15.7 15.7 15.7 15.7 15.7 15.7 15.7 15.6 15.6 15.6
kW 0.55 0.75 0.82 0.89 0.97 1.06 1.16 1.24 1.36 1.44 1.55 1.68 1.79 1.89 2.04 2.23 2.40
1080
60
TC 39.0 39.0 38.9 38.8 38.0 35.8 34.0 31.3 28.7 27.8 27.3 25.8 26.4 25.0 23.9 22.8 21.1
kW 1.66 1.96 2.11 2.30 2.41 2.36 2.36 2.30 2.24 2.21 2.49 2.44 2.38 2.33 2.27 2.23 2.19
70
TC 29.1 29.1 29.1 29.1 29.1 29.0 29.0 28.7 28.2 27.4 27.0 25.2 26.2 24.7 23.6 22.5 20.8
kW 1.35 1.45 1.58 1.70 1.85 1.98 2.14 2.31 2.45 2.40 2.69 2.63 2.56 2.50 2.44 2.38 2.33
75
TC 24.0 24.0 24.0 24.0 23.9 23.9 23.9 23.8 23.8 23.7 23.7 23.7 23.1 21.4 19.6 17.9 16.6
kW 0.98 1.20 1.30 1.41 1.52 1.67 1.81 1.94 2.08 2.20 2.39 2.57 2.67 2.60 2.53 2.47 2.42
80
TC 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.1 19.0 19.0 18.8 18.8 18.8 17.7 16.4
kW 0.79 0.99 1.07 1.15 1.26 1.35 1.45 1.55 1.72 1.81 1.95 2.06 2.18 2.35 2.54 2.56 2.50
Table 15
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
