Service Manual Bosch IDS 2.0 | 23
Bosch Thermotechnology Corp. | 07.2021
Data subject to change
BOVA 36+BVA 36 For Heating
Airfl ow
(CFM)
ID
(°F)
OD
(°F)
86 72 67 62 57 52 47 42 37 32 27 22 17 12 7 2 -4
650
60
TC 30.1 30.1 30.1 30.1 30.1 29.8 29.7 29.7 29.7 29.7 29.7 28.1 26.1 24.2 22.3 20.5 18.9
kW 1.08 1.43 1.58 1.71 1.86 1.98 2.16 2.39 2.62 2.82 3.10 3.04 2.92 2.82 2.72 2.62 2.54
70
TC 23.2 23.2 23.0 23.0 23.0 23.0 23.0 22.9 22.8 22.7 22.7 22.7 22.7 22.7 21.7 19.9 18.3
kW 0.82 1.06 1.18 1.28 1.40 1.51 1.64 1.82 1.97 2.07 2.28 2.46 2.66 2.89 2.94 2.83 2.74
75
TC 19.4 19.4 19.3 19.3 19.3 19.3 19.3 19.2 19.2 19.2 19.2 19.0 19.0 19.0 19.0 19.0 18.1
kW 0.73 0.90 0.98 1.07 1.18 1.28 1.39 1.50 1.64 1.78 1.93 2.03 2.19 2.38 2.59 2.84 2.86
80
TC 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.8 15.7 15.7 15.7 15.7 15.7 15.5 15.5 15.5 14.5
kW 0.68 0.73 0.81 0.88 0.97 1.05 1.14 1.25 1.38 1.46 1.57 1.68 1.80 1.92 2.09 2.30 2.30
820
(Low
Stage)
60
TC 34.6 34.6 34.6 34.3 34.3 34.2 34.2 34.1 32.6 30.6 30.5 28.6 26.4 24.5 22.7 20.8 19.3
kW 1.42 1.71 1.86 1.99 2.18 2.36 2.57 2.85 2.87 2.78 3.05 2.95 2.85 2.76 2.67 2.59 2.52
70
TC 26.5 26.5 26.5 26.5 26.5 26.5 26.4 26.2 26.2 26.2 26.2 26.2 25.9 24.0 22.0 20.3 18.8
kW 1.02 1.28 1.40 1.53 1.65 1.80 1.95 2.09 2.30 2.46 2.69 2.91 3.09 2.99 2.88 2.79 2.71
75
TC 22.3 22.3 22.3 22.3 22.3 22.2 22.2 22.0 22.1 21.9 21.9 21.9 21.9 21.9 21.8 19.9 18.4
kW 0.96 1.08 1.17 1.27 1.39 1.49 1.62 1.73 1.94 2.03 2.22 2.39 2.58 2.80 3.01 2.91 2.82
80
TC 18.3 18.3 18.3 18.3 18.3 18.2 18.2 18.2 18.1 18.1 18.1 18.1 17.9 17.9 17.9 18.0 18.0
kW 0.82 0.88 0.96 1.05 1.14 1.24 1.35 1.46 1.59 1.69 1.83 1.96 2.08 2.26 2.45 2.69 2.91
1020
60
TC 41.3 41.0 41.0 40.9 40.9 40.8 39.3 36.1 33.4 31.0 31.1 29.2 27.9 26.1 24.2 22.6 21.1
kW 1.69 2.18 2.33 2.53 2.74 2.96 2.98 2.87 2.77 2.69 2.96 2.88 2.80 2.72 2.65 2.57 2.52
70
TC 31.7 31.7 31.7 31.7 31.6 31.3 31.2 31.2 31.2 30.5 30.5 28.4 27.5 25.6 23.8 22.3 20.7
kW 1.27 1.63 1.72 1.89 2.02 2.17 2.36 2.60 2.83 2.94 3.22 3.12 3.03 2.93 2.85 2.76 2.69
75
TC 26.7 26.7 26.6 26.6 26.6 26.6 26.6 26.2 26.2 26.2 26.2 26.2 26.1 24.2 22.3 20.4 18.9
kW 1.06 1.36 1.46 1.58 1.70 1.86 2.01 2.14 2.34 2.50 2.74 2.95 3.16 3.06 2.97 2.88 2.80
80
TC 21.9 21.9 21.9 21.9 21.9 21.8 21.8 21.7 21.7 21.7 21.5 21.5 21.5 21.5 21.5 20.1 18.6
kW 0.86 1.13 1.20 1.30 1.41 1.51 1.64 1.76 1.95 2.07 2.20 2.37 2.56 2.76 3.01 3.00 2.92
1150
(High
Stage)
60
TC 45.9 45.8 45.8 45.7 44.5 42.0 39.8 36.7 33.9 31.7 31.6 29.3 28.5 26.6 24.7 23.1 21.5
kW 1.97 2.58 2.73 2.95 3.03 2.95 2.92 2.83 2.74 2.68 2.94 2.86 2.79 2.72 2.65 2.58 2.53
70
TC 35.6 35.5 35.3 35.0 35.0 35.0 34.8 34.7 33.1 31.0 30.9 28.9 28.2 26.0 24.1 22.6 21.0
kW 1.50 1.88 2.01 2.13 2.31 2.51 2.66 3.00 2.99 2.91 3.18 3.10 3.01 2.93 2.85 2.77 2.71
75
TC 29.9 29.9 29.8 29.6 29.8 29.7 29.3 29.3 29.4 29.4 29.4 28.5 26.5 24.6 22.6 20.6 19.2
kW 1.23 1.58 1.68 1.79 1.97 2.08 2.24 2.46 2.68 2.87 3.15 3.23 3.14 3.05 2.96 2.88 2.81
80
TC 24.5 24.5 24.5 24.5 24.5 24.5 24.4 24.4 24.1 24.1 24.0 24.1 24.1 24.1 22.3 20.3 18.9
kW 1.01 1.30 1.38 1.50 1.61 1.73 1.86 2.05 2.17 2.32 2.52 2.72 2.92 3.16 3.09 2.99 2.92
1350
60
TC 51.1 51.0 50.2 47.4 45.3 42.7 40.5 37.2 34.4 32.2 32.1 30.0 28.9 27.0 25.1 23.5 21.9
kW 2.38 3.03 3.10 3.03 3.01 2.94 2.92 2.83 2.76 2.70 2.96 2.89 2.83 2.77 2.70 2.64 2.59
70
TC 39.2 39.2 39.1 39.1 39.1 39.0 39.0 36.4 33.6 31.5 31.4 29.4 28.4 26.5 24.6 23.0 21.4
kW 1.74 2.16 2.30 2.50 2.70 2.91 3.14 3.09 3.00 2.93 3.20 3.12 3.04 2.97 2.90 2.82 2.77
75
TC 33.4 33.4 33.3 33.3 32.9 32.9 32.8 32.9 32.8 31.1 31.0 29.0 27.0 25.0 23.0 21.2 19.7
kW 1.47 1.84 1.95 2.12 2.22 2.40 2.60 2.85 3.09 3.06 3.34 3.25 3.17 3.09 3.01 2.93 2.87
80
TC 27.5 27.5 27.4 27.4 27.4 27.4 27.3 26.9 26.9 27.0 26.9 26.9 26.6 24.7 22.7 20.8 19.3
kW 1.22 1.53 1.62 1.75 1.86 2.02 2.17 2.31 2.51 2.67 2.91 3.12 3.30 3.21 3.13 3.04 2.97
Table 16
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
