28
|
Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
9 Refrigerant Flow Diagrams
9.1 Cooling Operation
Figure 7
Liquid Service Valve
Suction Service Valve
Accumulator
INV
FAN
Reversing
Valve
Strainer
Strainer
EEV
T4
Check valve
Condenser
Coil
T3
T5
HPS
Pressure
Transducer
A
E
H
D
C
J
B
G
F
Compressor
I
Gauge port of heat pump
FAN
FAN ON
Indoor unit
Thermostat "ON"
N
Th
Strainer
T3L
M
PEV
L
Bi-flow Filter Drier
P
TXV
O
Outdoor unit
High pressure gas
High pressure liquid
Low pressure
Evaporator
Coil
     Refrigerant ow during cooling operation/cooling oil return
operation/defrost operation
