6.2 Bosch IDS BOVA2.0
BOVA 36 BOVA 60
Cooling Capacity
Nominal Cooling (BTU/h) 34,600 54,500
Nominal Heating (BTU/h) 34,200 56,000
Decibels([dB(A)]
Max @ 100% load 77 79
Min @ min load 56 60
Compressor
RLA 19 29
LRA 44 52
Condenser Fan Motor
Horsepower (HP) 1/3 1/3
FLA 2.5 2.5
Refrigeration System
Refrigerant Line Size¹
Liquid Line Size (OD) 3/8" 3/8"
Suction Line Size (OD) 3/4" 7/8"
Refrigerant Connection Size
Liquid Valve Size (OD) 3/8" 3/8"
Suction Valve Size (OD) 3/4" 7/8"
Refrigerant Charge (R410-A, oz) 7 lbs. 9 oz. 11 lbs. 5 oz.
Expansion Device EEV EEV
Maximum Line Length 150 FT 150 FT
Maximum Elevation Diff erence 50 FT 50 FT
Operating Range
Cooling 15-125 °F
Heating -4~86 ° F
Electrical Data
Voltage-Phase-Hz 208/230-1-60 208/230-1-60
Minimum Circuit Ampacity² 26.3 38.8
Max. Overcurrent Protection³ 45 60
Max Fuse Size 45 60
Min/Max Volts 172V/270V
Weight
Net Weight (without packaging) 150 220
Gross Weight (including packaging)⁴
180 253
Dimensions
Unit L x W x H (in.) 29-1/8 x 29-1/8 x 24-15/16 29-1/8 x 29-1/8 x 33-3/16
Outdoor Coil
Net face area - sq.ft. Outer Coil 13.6 18.4
Tube diameter-in. 9/32" (7mm) 9/32" (7mm)
No.of rows 2 2.8
Fins per inch 17 19
Table 6
¹ Tested and rated in accordance with AHRI Standard 210/240.
² Wire size should be determined in accordance with National Electrical Codes;
extensive wire runs will require larger wire sizes.
³ Must use time-delay fuses or HACR-type circuit breakers of the same size as
noted.
⁴ Weight values are estimated.
• Always check the rating plate for electrical data on the unit being
installed.
• Unit is factory charged with refrigerant for 15’ of ⅜” liquid line.
System charge must be adjusted per Installation Instructions Final
Charge Procedure.
• TXV is required at indoor unit to match our outdoor unit.
