8.2 5 Ton
Figure 6
Fan motor


T5

HPS

T3

T3L

PT RV
Condenser
Accumulator

Compressor
EEV

Heat sink

Tf

T4

Th
PEV
Note: Please reference Table 18 for abbreviaon and parts descripon.
