11.4 Check Point Values
To display system parameters, press the “check” button on the outdoor board
to index through the series of parameters available. The fi rst time you press the
“check” button, it will display the sequence, and after 1 second it will display the
value of the parameter. If you press the “check” button again, it will display the next
sequence.
After 20 seconds on the same parameter, display will revert back to normal status.
No. Point check content Example Remark
0 Outdoor unit capacity H3 H3 = Heat pump 3 ton
1 Outdoor unit mode 2
0 standby
2 cooling
3 heating
2 Outdoor unit set compressor speed(Hz) 66
3 T3 (outdoor coil temp.) (°F )
4 T4 (outdoor ambient temp.) (°F )
5 T5 (compressor discharge temp.) (°F )
6 T6 (compressor suction temp.) (°F )
7 T7 (liquid line temp.) (°F )
8 Tf (module temp.) (°F )
9 Pe (evaporating pressure) (PSI) Low (suction) Pressure
10 Pc (condensing pressure) (PSI) High (head) Pressure
11 Tes (target of the evaporating temp. ) (only use for cooling mode) (°F )
12 Te (evaporating temp.) (°F )
13 Tcs (target of the condensing temp.) (only use for heatling mode) (°F )
14 Tc (condensing temp.) (°F )
15 Target of the compressor discharge superheat (only use for heating mode) (°F )
16 Compressor discharge superheat (°F )
17 Openings of EEV
18 Fan speed
19 Compressor current (A)
20 Alternating voltage (V)
21 Compressor input dc voltage (V)
22 Continuous running time of the compressor (min)
23 Last Fault Code 00
24 Software version 01
25 Remark“--” -- --
Table 26 Check Point Values
It is recommended to use the "check" button to verify outdoor unit
capacity (No. 0), operation mode (No. 1), and subcooling (No. 7 minus
No. 3 (will be within 2 degrees of measured gauge values)) prior to
leaving the installation site. See IOM for required subcool values.
