24
|
Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
BOVA 60+BVA 48 For Heating
Airfl ow
(CFM)
ID
(°F)
OD
(°F)
86 72 67 62 57 52 47 42 37 32 27 22 17 12 7 2 -4
1180
(Low
Stage)
60
TC 53.4 53.4 53.4 53.3 53.3 53.2 52.9 52.7 48.7 45.7 42.9 41.5 39.7 38.3 36.5 34.7 32.9
kW 2.11 2.57 2.81 3.05 3.31 3.57 3.86 4.21 4.04 3.91 4.11 4.50 4.50 4.38 4.31 4.23 4.07
70
TC 41.1 41.1 41.0 41.1 41.0 41.0 40.9 40.8 41.0 40.8 38.7 37.5 35.9 34.6 33.0 31.4 29.7
kW 1.68 2.01 2.15 2.31 2.53 2.70 2.94 3.20 3.49 3.71 3.90 4.27 4.27 4.16 4.08 4.01 3.86
75
TC 34.7 34.7 34.6 34.6 34.6 34.6 34.5 34.4 34.6 34.6 34.6 34.4 34.3 34.2 32.5 30.6 28.4
kW 1.46 1.75 1.85 1.99 2.15 2.29 2.45 2.70 2.93 3.13 3.40 3.62 3.90 4.22 4.47 4.30 4.16
80
TC 28.6 28.6 28.5 28.5 28.5 28.5 28.4 28.4 28.5 28.5 28.5 28.5 28.5 28.2 28.2 28.2 27.9
kW 1.25 1.50 1.60 1.70 1.84 1.95 2.09 2.23 2.42 2.59 2.77 2.99 3.21 3.42 3.71 4.05 4.34
1330
60
TC 57.3 57.3 57.2 57.1 57.1 56.8 56.9 53.3 49.2 46.1 43.8 42.4 40.6 39.2 37.4 35.5 33.7
kW 2.23 2.86 3.06 3.32 3.59 3.87 4.21 4.14 3.99 3.83 4.03 4.41 4.41 4.29 4.22 4.14 3.99
70
TC 44.1 44.0 44.0 44.0 43.9 43.8 43.8 43.7 43.7 43.7 41.6 40.2 38.5 37.2 35.4 33.7 31.9
kW 1.75 2.19 2.32 2.52 2.71 2.92 3.17 3.46 3.75 4.04 4.24 4.65 4.65 4.53 4.45 4.36 4.20
75
TC 37.1 37.1 37.0 37.0 37.0 37.0 36.9 36.8 36.9 36.9 36.8 36.8 36.8 35.0 33.5 31.7 29.8
kW 1.54 1.90 1.99 2.13 2.30 2.45 2.69 2.90 3.16 3.37 3.65 3.92 4.23 4.27 4.15 4.06 3.89
80
TC 30.6 30.6 30.5 30.5 30.5 30.5 30.5 30.5 30.4 30.4 30.4 30.4 30.4 30.2 30.3 30.2 28.2
kW 1.36 1.63 1.72 1.82 1.97 2.08 2.23 2.39 2.62 2.77 3.00 3.21 3.43 3.69 4.01 4.40 4.33
1530
(High
Stage)
60
TC 63.0 63.0 63.0 62.8 62.7 62.0 58.8 53.7 49.9 46.6 44.3 42.9 41.0 39.6 37.8 35.9 34.0
kW 2.49 3.27 3.49 3.76 4.07 4.31 4.25 4.08 3.96 3.85 4.04 4.43 4.43 4.31 4.24 4.16 4.00
70
TC 48.6 48.6 48.5 48.4 48.4 48.3 48.2 48.2 48.2 45.6 43.3 42.0 40.1 38.8 36.9 35.1 33.3
kW 1.98 2.46 2.63 2.83 3.07 3.30 3.61 3.91 4.25 4.19 4.40 4.82 4.82 4.70 4.61 4.53 4.36
75
TC 40.9 40.9 40.8 40.8 40.6 40.7 40.7 40.6 40.7 40.6 40.6 40.6 40.1 38.1 36.5 34.5 32.5
kW 1.72 2.13 2.24 2.39 2.56 2.78 3.01 3.27 3.54 3.77 4.12 4.43 4.76 4.81 4.66 4.57 4.38
80
TC 33.7 33.7 33.6 33.6 33.6 33.6 33.5 33.5 33.5 33.5 33.5 33.5 33.4 33.4 33.4 31.0 28.7
kW 1.52 1.83 1.92 2.04 2.19 2.33 2.49 2.72 2.93 3.12 3.38 3.60 3.85 4.16 4.53 4.63 4.67
1760
60
TC 68.9 68.7 68.7 68.7 66.8 63.0 59.7 54.8 50.6 46.8 44.4 43.0 41.2 39.8 37.9 36.0 34.1
kW 2.89 3.70 3.95 4.28 4.40 4.29 4.24 4.10 3.97 3.87 4.06 4.45 4.45 4.33 4.25 4.18 4.02
70
TC 53.2 53.2 53.2 53.0 53.0 52.9 52.7 52.8 49.4 46.3 44.0 42.6 40.7 39.3 37.5 35.6 33.8
kW 2.24 2.77 2.98 3.21 3.47 3.72 4.00 4.39 4.33 4.22 4.43 4.85 4.85 4.72 4.64 4.55 4.39
75
TC 44.9 44.9 44.9 44.8 44.8 44.7 44.6 44.6 44.6 44.5 44.5 42.0 40.6 38.6 36.9 34.9 32.9
kW 1.95 2.39 2.53 2.72 2.92 3.13 3.38 3.67 3.97 4.25 4.65 4.93 4.78 4.83 4.69 4.59 4.40
80
TC 37.1 37.0 36.9 36.9 36.9 36.9 36.8 36.7 36.8 36.8 36.7 36.7 36.7 36.7 34.5 31.6 29.3
kW 1.72 2.07 2.16 2.29 2.46 2.61 2.84 3.05 3.29 3.50 3.76 4.03 4.32 4.69 4.68 4.77 4.82
1900
60
TC 74.0 74.0 74.0 70.9 67.5 63.6 59.9 54.7 50.5 47.7 45.3 43.9 42.0 40.6 38.6 36.7 34.8
kW 3.63 4.07 4.39 4.40 4.35 4.25 4.20 4.06 3.95 3.88 4.07 4.46 4.46 4.34 4.26 4.19 4.03
70
TC 57.5 57.5 57.5 57.4 57.4 56.9 56.9 54.0 49.9 46.7 44.3 42.9 41.1 39.7 37.8 35.9 34.1
kW 2.83 3.05 3.31 3.56 3.83 4.08 4.41 4.45 4.42 4.41 4.63 5.08 5.08 4.94 4.85 4.77 4.59
75
TC 48.7 48.7 48.7 48.6 48.6 48.5 48.3 48.2 48.2 47.1 46.0 43.0 40.9 38.8 37.2 35.1 33.1
kW 2.41 2.60 2.80 2.99 3.24 3.46 3.72 4.04 4.38 4.40 5.06 4.92 4.78 4.83 4.69 4.59 4.40
80
TC 40.2 40.2 40.2 40.2 40.2 40.1 40.0 39.9 40.1 40.0 39.8 39.8 39.8 37.8 34.9 31.9 29.6
kW 1.96 2.24 2.37 2.52 2.69 2.90 3.11 3.36 3.63 3.82 4.15 4.45 4.79 4.83 4.68 4.78 4.82
Table 17
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
