Bosch IDS 2.0 Service Manual
07.2021 | Bosch Thermotechnology Corp.
Data subject to change
BOVA 60 +BVA 60 For Cooling
Indoor
Airfl ow (CFM)
Outdoor
DB (°F)
IWB (°F) 59 63 67 71
IDB (°F) 70 75 80 85 70 75 80 85 70 75 80 85 70 75 80 85
1160
15
TC 39.1 39.6 40.4 40.9 40.4 40.9 41.3 41.8 43.2 43.6 44.0 44.4 / 51.9 52.3 53.3
S/T 0.65 0.70 0.78 1.00 0.59 0.77 0.81 0.86 0.40 0.54 0.68 0.83 / 0.38 0.51 0.62
kW 1.54 1.56 1.57 1.57 1.57 1.59 1.61 1.62 1.61 1.64 1.66 1.68 / 2.24 2.27 2.06
65
TC 39.2 39.6 40.5 41.0 40.5 41.0 41.4 41.8 43.3 43.7 44.1 44.5 / 52.0 52.4 53.4
S/T 0.77 0.82 0.90 1.00 0.59 0.77 0.88 0.93 0.40 0.54 0.68 0.83 / 0.38 0.51 0.62
kW 1.91 1.94 1.96 1.96 1.96 1.98 2.00 2.02 2.01 2.04 2.06 2.08 / 2.64 2.67 2.46
75
TC 39.0 39.4 40.3 40.7 40.3 40.7 41.2 41.6 43.0 43.4 43.8 44.2 / 52.3 52.7 53.2
S/T 0.77 0.82 0.90 1.00 0.59 0.77 0.89 0.94 0.40 0.54 0.69 0.83 / 0.38 0.51 0.62
kW 2.18 2.20 2.22 2.22 2.22 2.25 2.27 2.29 2.29 2.31 2.34 2.37 / 2.64 2.67 2.69
85
TC 38.6 39.0 39.9 40.3 39.9 40.3 40.7 41.2 42.6 43.0 43.3 43.8 / 51.5 51.9 52.3
S/T 0.77 0.82 0.90 1.00 0.59 0.77 0.89 0.94 0.40 0.54 0.69 0.83 / 0.38 0.51 0.63
kW 2.31 2.33 2.36 2.36 2.36 2.38 2.41 2.43 2.44 2.46 2.48 2.51 / 3.01 3.04 3.06
95
TC 38.2 38.6 39.5 39.9 39.5 39.9 40.4 40.8 42.2 42.6 42.9 43.3 / 50.7 51.1 51.5
S/T 0.78 0.83 0.91 1.00 0.59 0.77 0.89 0.94 0.39 0.54 0.69 0.84 / 0.38 0.51 0.63
kW 2.79 2.82 2.85 2.85 2.85 2.88 2.91 2.94 2.94 2.97 3.00 3.02 / 3.61 3.64 3.67
105
TC 37.7 38.1 39.0 39.4 39.0 39.4 39.8 40.2 41.7 42.0 42.3 42.7 / 49.8 50.2 50.5
S/T 0.78 0.83 0.91 1.00 0.59 0.78 0.89 0.94 0.39 0.55 0.70 0.84 / 0.38 0.51 0.64
kW 3.33 3.36 3.40 3.40 3.40 3.43 3.47 3.50 3.52 3.55 3.58 3.61 / 4.29 4.32 4.36
115
TC 37.2 37.6 38.4 38.8 38.4 38.8 39.3 39.7 41.1 41.4 41.8 42.1 / 45.5 45.7 46.0
S/T 0.78 0.83 0.91 1.00 0.59 0.78 0.93 0.98 0.39 0.55 0.70 0.85 / 0.39 0.52 0.66
kW 3.96 4.00 4.04 4.04 4.04 4.09 4.13 4.17 4.18 4.22 4.26 4.29 / 4.35 4.36 4.36
125
TC 29.2 29.5 30.2 30.5 30.2 30.5 30.8 31.2 32.7 32.8 32.8 32.9 / 34.8 34.8 34.9
S/T 0.79 0.84 0.92 1.00 0.60 0.81 0.93 0.98 0.40 0.59 0.78 1.00 / 0.39 0.58 0.76
kW 3.13 3.16 3.19 3.19 3.19 3.23 3.26 3.30 3.36 3.36 3.36 3.36 / 3.39 3.39 3.39
1320
(Low Stage)
15
TC 41.6 42.1 43.0 43.5 43.0 43.5 43.9 44.4 46.0 46.4 46.8 47.2 / 56.0 56.5 56.9
S/T 0.69 0.74 0.82 1.00 0.59 0.79 0.81 0.86 0.39 0.55 0.70 0.85 / 0.38 0.51 0.64
kW 1.68 1.70 1.71 1.71 1.71 1.73 1.75 1.77 1.76 1.78 1.81 1.84 / 2.22 2.25 2.28
65
TC 41.8 42.3 43.2 43.7 43.2 43.7 44.2 44.7 46.2 46.6 47.0 47.4 / 56.2 56.7 57.1
S/T 0.81 0.86 0.94 1.00 0.59 0.79 0.90 0.95 0.39 0.55 0.70 0.85 / 0.38 0.51 0.64
kW 2.15 2.18 2.20 2.20 2.20 2.22 2.24 2.27 2.26 2.28 2.31 2.34 / 2.72 2.75 2.78
75
TC 41.9 42.4 43.4 43.8 43.4 43.8 44.3 44.8 46.3 46.7 47.1 47.5 / 55.8 56.3 56.7
S/T 0.80 0.85 0.93 1.00 0.59 0.79 0.90 0.95 0.39 0.55 0.70 0.85 / 0.38 0.51 0.64
kW 2.31 2.33 2.36 2.36 2.36 2.38 2.41 2.43 2.43 2.45 2.48 2.51 / 2.93 2.96 2.99
85
TC 41.4 41.9 42.8 43.3 42.8 43.3 43.8 44.2 45.8 46.2 46.6 46.9 / 55.0 55.4 55.8
S/T 0.80 0.85 0.93 1.00 0.59 0.79 0.90 0.95 0.39 0.55 0.71 0.86 / 0.38 0.51 0.64
kW 2.55 2.58 2.61 2.61 2.61 2.63 2.66 2.69 2.70 2.72 2.74 2.77 / 3.30 3.33 3.36
95
TC 40.9 41.4 42.3 42.7 42.3 42.7 43.2 43.7 45.2 45.5 46.0 46.3 / 53.9 54.3 54.7
S/T 0.80 0.85 0.93 1.00 0.59 0.79 0.90 0.95 0.39 0.55 0.70 0.86 / 0.38 0.52 0.65
kW 3.06 3.09 3.13 3.13 3.13 3.16 3.19 3.23 3.23 3.26 3.29 3.32 / 3.93 3.97 4.00
105
TC 40.2 40.7 41.6 42.0 41.6 42.0 42.5 42.9 44.5 44.9 45.2 45.5 / 52.8 53.1 53.4
S/T 0.80 0.85 0.93 1.00 0.60 0.80 0.90 0.95 0.39 0.56 0.71 0.87 / 0.38 0.52 0.66
kW 3.63 3.67 3.71 3.71 3.71 3.75 3.79 3.83 3.84 3.88 3.91 3.94 / 4.67 4.71 4.74
115
TC 38.3 38.7 39.6 40.0 39.6 40.0 40.5 40.9 42.6 42.9 43.0 42.8 / 45.8 46.0 46.2
S/T 0.81 0.86 0.94 1.00 0.60 0.80 0.90 0.95 0.39 0.56 0.73 0.90 / 0.39 0.54 0.70
kW 4.06 4.10 4.15 4.15 4.15 4.19 4.24 4.28 4.36 4.37 4.37 4.36 / 4.41 4.41 4.41
125
TC 29.5 29.9 30.5 30.9 30.5 30.9 31.2 31.5 33.1 33.1 33.2 33.3 / 35.2 35.3 35.3
S/T 0.83 0.88 0.96 1.00 0.62 0.86 0.91 0.96 0.40 0.61 0.83 1.00 / 0.40 0.60 0.81
kW 3.18 3.21 3.25 3.25 3.25 3.28 3.32 3.35 3.42 3.42 3.42 3.42 / 3.44 3.44 3.44
1520
15
TC 45.9 46.4 47.4 47.9 47.4 47.9 48.5 49.0 50.7 51.2 51.6 52.0 / 60.6 61.1 61.5
S/T 0.72 0.77 0.85 1.00 0.60 0.81 0.86 0.91 0.39 0.55 0.72 0.87 / 0.38 0.52 0.65
kW 1.87 1.89 1.91 1.91 1.91 1.93 1.95 1.97 1.94 1.98 2.02 2.06 / 2.44 2.47 2.49
65
TC 48.0 48.5 49.6 50.1 49.6 50.1 50.7 51.2 53.1 53.5 53.9 54.3 / 62.9 63.4 63.8
S/T 0.85 0.90 0.98 1.00 0.60 0.80 0.93 0.98 0.39 0.55 0.70 0.85 / 0.38 0.51 0.64
kW 2.55 2.57 2.60 2.60 2.60 2.63 2.66 2.68 2.68 2.71 2.74 2.77 / 3.13 3.17 3.20
75
TC 47.6 48.2 49.2 49.8 49.2 49.8 50.3 50.8 52.7 53.2 53.5 53.9 / 62.3 62.7 63.1
S/T 0.85 0.90 0.98 1.00 0.60 0.80 0.93 0.98 0.39 0.55 0.70 0.86 / 0.38 0.52 0.65
kW 2.75 2.78 2.81 2.81 2.81 2.84 2.87 2.90 2.91 2.93 2.96 2.98 / 3.43 3.46 3.50
85
TC 46.8 47.3 48.4 48.9 48.4 48.9 49.4 49.9 51.8 52.2 52.6 53.0 / 60.8 61.3 61.7
S/T 0.85 0.90 0.98 1.00 0.60 0.80 0.93 0.98 0.39 0.55 0.71 0.87 / 0.38 0.52 0.65
kW 3.09 3.12 3.15 3.15 3.15 3.19 3.22 3.25 3.27 3.30 3.32 3.35 / 3.94 3.98 4.01
95
TC 45.9 46.4 47.4 48.0 47.4 48.0 48.5 49.0 50.8 51.2 51.6 51.9 / 59.3 59.7 60.1
S/T 0.85 0.90 0.98 1.00 0.60 0.81 0.93 0.98 0.39 0.55 0.72 0.87 / 0.38 0.52 0.66
kW 3.66 3.70 3.74 3.74 3.74 3.78 3.82 3.86 3.87 3.90 3.93 3.96 / 4.66 4.69 4.72
105
TC 44.8 45.3 46.3 46.8 46.3 46.8 47.4 47.9 49.7 50.0 50.4 50.7 / 57.7 57.9 57.9
S/T 0.85 0.90 0.98 1.00 0.60 0.81 0.93 0.98 0.39 0.56 0.72 0.89 / 0.38 0.53 0.67
kW 4.31 4.36 4.40 4.40 4.40 4.45 4.50 4.54 4.56 4.60 4.64 4.67 / 5.46 5.48 5.48
115
TC 38.4 38.9 39.7 40.2 39.7 40.2 40.6 41.0 42.8 43.0 43.2 43.3 / 44.7 44.8 45.0
S/T 0.85 0.90 0.98 1.00 0.61 0.82 0.93 0.98 0.39 0.59 0.78 1.00 / 0.39 0.58 0.76
kW 4.25 4.30 4.34 4.34 4.34 4.39 4.43 4.48 4.53 4.55 4.57 4.46 / 4.60 4.62 4.63
125
TC 29.8 30.1 30.8 31.1 30.8 31.1 31.5 31.8 33.4 33.4 33.5 33.5 / 35.5 35.6 35.7
S/T 0.86 0.91 0.99 1.00 0.65 0.92 0.93 0.98 0.40 0.65 0.90 1.00 / 0.40 0.64 0.87
kW 3.26 3.30 3.34 3.34 3.34 3.37 3.41 3.44 3.51 3.51 3.51 3.51 / 3.53 3.53 3.53
Table 13
TC refer to total capacity S/T: refer to the ratio of sensible heat and total capacity kW: refer to total input power
