Symbols specifically for this Machine
In addition, observe detailed handling instructions in the OPERATING INSTRUCTIONS Section.
/ Hex socket drive/Square drive Type of tool holder
Arrow Action in the direction of arrow
Alternating current Type or a characteristic of current
Direct current Type or a characteristic of current
Alternating or direct current Type or a characteristic of current
Class II construction Designates double insulated constructed tools
Protection class I
(Earthing terminal)
Machines of the protection class I must be earthed
Warning symbol Alerts user to warning messages.
Read and understand instructions before opera
tion
Warning symbol Provides information for correct handling, e.g.,
read the operating instructions.
Symbol Name Meaning
Symbol Meaning
Warning symbol Do not direct the laser beam at persons or an?
imals and do not look into the laser beam,
also not from greater distances. This machine
generates laser radiation of the laser class 2 ac
cording to EN 608252:2001. Unintentional blind
ing of other persons could result if not observed.
Note symbol The power tool, accessories and packaging
should be recycled in an environmentally friendly
manner.
Only for EU countries:
Do not throw power tools in the household waste!
According to the European Guide Lines
2002/96/EG on old electric and electronic equip
ment and their translation into national laws, power
tools that are no longer usable must be collected
separately and recycled in an environmentally
friendly manner.
Warning symbol Wear protective glasses.
