Bosch PRS-1AIP1 - Multicast; Re-Broadcast

Multicast
Multicast means: predefined receiver devices (Partners) each receive a single data stream in a
LAN or WAN. Typical partner IP addresses between: 224.0.0.1 to 239.255.255.255.
1
Figure 5.4: Multicasting example (1=LAN/WAN)
Re-broadcast
Re-broadcast means: a local device receives a data stream from a remote device and resends
it to other devices (Partners) in a LAN or WAN.
1
3
2 2
Figure 5.5: Re-broadcasting (1=Internet, 2=Router, 3=LAN/WAN)
5.4
5.5
IP Audio Interface Connection options | en 15
Bosch Security Systems B.V. Operating Manual 2013.03 | V2.0 |
