Configuration
The IP Audio Interface uses dynamic HTML web pages for configuration and status information
monitoring. Configuration parameters are stored in the IP Audio Interface via the web
browser.
Caution!
Your configuration parameters will be lost if the device is reset to factory default settings, see
Front view, page 9.
Connect to web browser
Open a web browser on a PC that is connected to the same network as the IP Audio Interface.
IP address.
Enter the announced IP address of the IP Audio Interface in the web browser address (URL)
box, see IP address (step 4), page 12.
The built‑in web server generates the STATUS page in the web browser by default. If not,
repeat the installation process. The status screen is updated dynamically. The current
implementation of this feature does not support all web browsers, for example, Google
Chrome.
Figure 6.1: Status screen example
6
6.1
16 en | Configuration IP Audio Interface
2013.03 | V2.0 | Operating Manual Bosch Security Systems B.V.
